SPECjbb2015 Report for jbb2015-20190314-00399 : 327501 max-jOPS ; 108859 critical-jOPS

SUT Description

Hardware hw_1
Name	Cisco UCS C480 M5
Vendor	Cisco Systems
Vendor URL	http://www.cisco.com/
Available	April-2019
Model	Cisco UCS C480 M5
Form Factor	4U Rack
CPU Name	Intel Xeon Platinum 8280
CPU Characteristics	28Cores, 2.70 GHz, 38.5MB L3 Cache (Turbo Boost Technology up to 4.0 GHz)
Number of Systems	1
Nodes Per System	1
Chips Per System	4
Cores Per System	112
Cores Per Chip	28
Threads Per System	224
Threads Per Core	2
Version	Version 4.0.3.34
CPU Frequency (MHz)	2700
Primary Cache	32KB(I)+32KB(D) per core
Secondary Cache	1024 KB (I+D) per core
Tertiary Cache	38.5MB (I+D) on chip per chip
Other Cache	None
Disk	1x 400GB SSD SAS
File System	NTFS
Memory Amount (GB)	1536
# and size of DIMM(s)	48 x 32GB
Memory Details	1536 GB(48 X 32GB 2Rx4 PC4-2933V)
# and type of Network Interface Cards (NICs)	2 x 10 Gbit NIC
Power Supply Quantity and Rating (W)	4 x 1600W
Other Hardware	None
Cabinet/Housing/Enclosure	None
Shared Description	None
Shared Comment	None
Notes	Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented. Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented. Yes: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented.
Other Hardware network_1
Name	None
Vendor	None
Vendor URL	None
Version	None
Available	None
Bitness	None
Notes	None

Operating System os_1
Name	Windows Server 2019 Datacenter
Vendor	Microsoft
Vendor URL	http://www.microsoft.com/
Version	Version 10.0.17763 Build 17763
Available	October 2018
Bitness	64
Notes	None
Java Virtual Machine jvm_1
Name	Oracle Java SE 11.0.2
Vendor	Oracle Corporation
Vendor URL	http://www.oracle.com
Version	Java HotSpot 64-bit Server VM, version 11.0.2
Available	Jan-2019
Bitness	64
Notes	None
Other Software other_1
Name	None
Vendor	None
Vendor URL	None
Version	None
Available	None
Bitness	None
Notes	None

Topology

SUT
- Hardware config_1
  - OS Image os_Image_1
    - JVM jvm_Ctr_1 : Controller
    - JVM jvm_Backend_1 : Backend
    - JVM jvm_TxInjector_1 : TxInjector

SUT config_1 Configuration

Hardware
OS Images	os_Image_1(1)
Hardware Description	hw_1
Number of Systems	1
SW Environment	non-virtual
Tuning	BIOS tuning Memory Patrol Scrub disabled CPU Performance set to Enterprise Hyperthreading Enabled IMC Interleave to one-way SNC Enabled Memory RAS configuration set to Maximum performance Power Technology set to performance
Notes	None

OS Image os_Image_1
JVM Instances	jvm_Ctr_1(1), jvm_Backend_1(8), jvm_TxInjector_1(8)
OS Image Description	os_1
Tuning	Power Options is set to High performance Processor scheduling is set to Programs Lock Pages in Memory is Enabled HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\Tcpip\Parameters and add a new entry . Value Name: MaxUserPort Value Type: DWORD Value data: 65534
Notes	None
JVM Instance jvm_Ctr_1
Parts of Benchmark	Controller
JVM Instance Description	jvm_1
Command Line	-Xmn1536m -Xms2g -Xmx2g
Tuning	None
Notes	None
JVM Instance jvm_Backend_1
Parts of Benchmark	Backend
JVM Instance Description	jvm_1
Command Line	-showversion -server -XX:LargePageSizeInBytes=2m -XX:-UseAdaptiveSizePolicy -XX:+AlwaysPreTouch -XX:-UseBiasedLocking -XX:+UseLargePages -XX:+UseParallelOldGC -Xms29g -Xmx29g -Xmn27g -XX:SurvivorRatio=28 -XX:TargetSurvivorRatio=95 -XX:ParallelGCThreads=28 -XX:MaxTenuringThreshold=15 -XX:AllocatePrefetchInstr=2 -XX:InlineSmallCode=10k -XX:+UseRTMLocking -XX:+UseRTMDeopt -XX:-UsePerfData
Tuning	Affinitized each Backend JVM to a NUMA node start /NODE [0-7]
Notes	None
JVM Instance jvm_TxInjector_1
Parts of Benchmark	TxInjector
JVM Instance Description	jvm_1
Command Line	-showversion -Xmn3584m -Xms4g -Xmx4g -XX:+UseLargePages -XX:+UseParallelOldGC -XX:LargePageSizeInBytes=2m
Tuning	Affinitized each Tx Injector JVM to a NUMA node start /NODE [0-7]
Notes	None

max-jOPS and critical-jOPS Details

max-jOPS = jOPS passed before the First Failure
Pass/Fail	Pass	Pass	Fail	Fail	Fail
jOPS	323555	327501	331446	335392	339338

critical-jOPS = Geomean ( jOPS @ 10000; 25000; 50000; 75000; 100000; SLAs )
Response time percentile is 99-th
SLA (us)	10000	25000	50000	75000	100000	Geomean
jOPS	65105	92726	116401	136130	159804	108859

Last Success jOPS/First Failure jOPS for SLA points

	Percentile
	10-th	50-th	90-th	95-th	99-th	100-th
500us	- / 3946	- / 3946	- / 3946	- / 3946	- / 3946	- / 3946
1000us	11837 / 15783	7892 / 11837	3946 / 7892	- / 3946	- / 3946	- / 3946
5000us	201235 / 197289	71024 / 74970	39458 / 43404	35512 / 39458	27621 / 31566	- / 3946
10000us	232802 / 236747	181506 / 161777	94699 / 98645	78916 / 82862	63133 / 67078	- / 3946
25000us	248585 / 252531	232802 / 236747	185452 / 189398	157832 / 161777	90753 / 94699	3946 / 7892
50000us	248585 / 252531	240693 / 244639	217018 / 220964	197289 / 201235	114428 / 118374	3946 / 7892
75000us	256476 / 260422	244639 / 248585	228856 / 232802	209127 / 213073	134157 / 138103	3946 / 7892
100000us	260422 / 264368	248585 / 252531	232802 / 236747	217018 / 220964	157832 / 161777	11837 / 15783
200000us	280151 / 276205	256476 / 260422	244639 / 248585	240693 / 244639	228856 / 232802	98645 / 35512
500000us	323555 / 327501	303826 / 299880	272260 / 276205	268314 / 272260	260422 / 264368	236747 / 240693
1000000us	327501 / -	327501 / -	319609 / 323555	311717 / 315663	307772 / 311717	272260 / 276205

Number of probes

Request Mix Accuracy

Note

(Actual % in the Mix - Expected % in the Mix) must be within:

'Main Tx' limit of +/-5.0% for the requests whose expected % in the mix is >= 10.0%

'Minor Tx' limit of +/-1.0% for the requests whose expected % in the mix is < 10.0%

Rate of Non-Critical Failures

There were no non-critical failures in Response Time curve building

Delay between performance status pings during RT Curve (Response-Throughput Curve)

IR/PR Accuracy

Run Properties

This section lists properties only set by user

Property Name	Default	Controller
specjbb.comm.connect.client.pool.size	256	192
specjbb.comm.connect.selector.runner.count	0	4
specjbb.comm.connect.timeouts.connect	60000	800000
specjbb.comm.connect.timeouts.read	60000	800000
specjbb.comm.connect.timeouts.write	60000	800000
specjbb.comm.connect.worker.pool.max	256	60
specjbb.comm.connect.worker.pool.min	1	60
specjbb.customerDriver.threads	64	{=64, probe=64, saturate=64, service=64}
specjbb.forkjoin.workers	56	{Tier1=170, Tier2=1, Tier3=26}
specjbb.group.count	1	8
specjbb.heartbeat.threshold	100000	600000
specjbb.mapreducer.pool.size	56	4
specjbb.txi.pergroup.count	1	1

View table in csv format

Validation Details

Validation Reports


Level: COMPLIANCE
Check	Agent	Result
Check properties on compliance	All	PASSED


Level: CORRECTNESS
Check	Agent	Result
Compare SM and HQ Inventory	All	PASSED

Other Checks

High-bound (max attempted) is 394579 IR

High-bound (settled) is 343266 IR

http://www.spec.org - info@spec.org

SPECjbb2015 Version: [SPECjbb2015 1.02, Jan 10, 2019]

Cisco Systems Cisco UCS C480 M5	327501 SPECjbb2015-MultiJVM max-jOPS 108859 SPECjbb2015-MultiJVM critical-jOPS
Tested by: Cisco Systems	Test Sponsor: Cisco Systems	Test location: San Jose, CA	Test date: March 12, 2019
SPEC license #: 9019	Hardware Availability: April-2019	Software Availability: Jan-2019	Publication: Tue Apr 2 15:05:14 EDT 2019
