SPECjbb2015
Copyright © 2015-2019 Standard Performance Evaluation Corporation
Hewlett Packard Enterprise ProLiant DL360 Gen10 81734 SPECjbb2015-MultiJVM max-jOPS
49374 SPECjbb2015-MultiJVM critical-jOPS
Tested by: Hewlett Packard Enterprise Test Sponsor: Hewlett Packard Enterprise Test location: Houston, TX Test date: Mar 12, 2019
SPEC license #: 3 Hardware Availability: Apr-2019 Software Availability: Mar-2019 Publication: Tue Apr 2 15:05:14 EDT 2019
Benchmark Results Summary

SPECjbb2015-MultiJVM: Multiple JVMs/Single Host
(# of groups: 1)
Overall Throughput RT curve
Overall Throughput RT curve
Overall SUT (System Under Test) Description
VendorHewlett Packard Enterprise
Vendor URLhttp://hpe.com/
System SourceSingle Supplier
System DesignationServer Rack
Total Systems1
All SUT Systems IdenticalYes
Total Nodes1
All Nodes IdenticalYes
Nodes Per System1
Total Chips1
Total Cores28
Total Threads56
Total Memory Amount (GB)768
Total OS Images1
SW EnvironmentNon-virtual

SUT Description
Hardware hw_1
NameProLiant DL360 Gen10
VendorHewlett Packard Enterprise
Vendor URLhttp://hpe.com/
AvailableApr-2019
ModelProLiant DL360 Gen10
Form Factor1U
CPU NameIntel Xeon Platinum 8280
CPU Characteristics28 Core, 2.70 GHz, 38.5 MB L3 Cache (Turbo Boost Technology up to 4.00 GHz)
Number of Systems1
Nodes Per System1
Chips Per System1
Cores Per System28
Cores Per Chip28
Threads Per System56
Threads Per Core2
VersionU30 2.00 02/02/2019
CPU Frequency (MHz)2700
Primary Cache32 KB I + 32 KB D On Chip Per Core
Secondary Cache1024 KB I+D On Chip Per Core
Tertiary Cache38.5 MB I+D On Chip Per Chip
Other CacheNone
Disk1 x 480 GB SSD SATA
File SystemNTFS
Memory Amount (GB)768
# and size of DIMM(s)12 x 64 GB
Memory Details64 GB 2Rx4 PC4-2933Y-R
# and type of Network Interface Cards (NICs)1 x HPE 331i 4 Port 1 Gbit Ethernet
Power Supply Quantity and Rating (W)2 x 1600
Other HardwareNone
Cabinet/Housing/EnclosureNone
Shared DescriptionNone
Shared CommentNone
Notes
  • Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented.
  • Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented.
  • Yes: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented.
Other Hardware network_1
NameNone
VendorNone
Vendor URLNone
VersionNone
AvailableNone
BitnessNone
NotesNone
Operating System os_1
NameWindows Server 2019 Standard
VendorMicrosoft
Vendor URLhttp://microsoft.com/
Version1809 (Build 17763.348)
AvailableMar-2019
Bitness64
NotesNone
Java Virtual Machine jvm_1
NameOracle Java SE 8u201
VendorOracle
Vendor URLhttp://www.oracle.com/
VersionJava HotSpot 64-bit Server VM (build 25.201-b09, mixed mode)
AvailableJan-2019
Bitness64
NotesNone
Other Software other_1
NameNone
VendorNone
Vendor URLNone
VersionNone
AvailableNone
BitnessNone
NotesNone
Topology
SUT config_1 Configuration
Hardware
OS Images os_Image_1(1)
Hardware Description hw_1
Number of Systems 1
SW Environment Non-virtual
Tuning
  • Workload Profile=High Performance Compute
  • Memory Patrol Scrubbing=Disabled
  • LLC Dead Line Allocation=Disabled
  • LLC Prefetch=Enabled
  • XPT Prefetcher=Enabled
  • Enhanced Processor Performance=Enabled
  • Thermal Configuration=Maximum Cooling
Notes None
OS Image os_Image_1
JVM Instances jvm_Ctr_1(1), jvm_Backend_1(1), jvm_TxInjector_1(1)
OS Image Description os_1
Tuning
  • Lock Pages In Memory=Enabled
  • Performance Options=Adjust For Best Performance
  • Power Options=High Performance
  • Processor Scheduling=Programs
Notes None
JVM Instance jvm_Ctr_1
Parts of Benchmark Controller
JVM Instance Description jvm_1
Command Line -server -Xms2g -Xmx2g -Xmn1536m -XX:+UseLargePages -XX:LargePageSizeInBytes=2m -XX:+UseParallelOldGC
Tuning None
Notes None
JVM Instance jvm_Backend_1
Parts of Benchmark Backend
JVM Instance Description jvm_1
Command Line -server -Xms350g -Xmx350g -Xmn340g -XX:+UseParallelOldGC -XX:ParallelGCThreads=56 -XX:+UseLargePages -XX:LargePageSizeInBytes=2m -XX:-UseBiasedLocking -XX:+AggressiveOpts -XX:+AlwaysPreTouch -XX:-UseAdaptiveSizePolicy -XX:SurvivorRatio=34 -XX:MaxTenuringThreshold=15 -XX:TargetSurvivorRatio=90 -XX:-UsePerfData -Xnoclassgc
Tuning None
Notes None
JVM Instance jvm_TxInjector_1
Parts of Benchmark TxInjector
JVM Instance Description jvm_1
Command Line -server -Xms2g -Xmx2g -Xmn1536m -XX:+UseLargePages -XX:LargePageSizeInBytes=2m -XX:+UseParallelOldGC
Tuning None
Notes None
max-jOPS and critical-jOPS Details
max-jOPS = jOPS passed before the First Failure
Pass/Fail Pass Pass Fail Fail Fail
jOPS 80713 81734 82756 83778 84799
critical-jOPS = Geomean ( jOPS @ 10000; 25000; 50000; 75000; 100000; SLAs )
Response time percentile is 99-th
SLA (us) 10000 25000 50000 75000 100000 Geomean
jOPS 35985 48530 52514 55425 57725 49374
Last Success jOPS/First Failure jOPS for SLA points
  Percentile
  10-th 50-th 90-th 95-th 99-th 100-th
500us - / 1022 - / 1022 - / 1022 - / 1022 - / 1022 - / 1022
1000us 46997 / 44954 3065 / 4087 1022 / 2043 1022 / 2043 1022 / 2043 - / 1022
5000us 55171 / 56192 55171 / 56192 54149 / 55171 54149 / 55171 43932 / 8173 - / 1022
10000us 72539 / 73561 55171 / 56192 54149 / 55171 54149 / 55171 43932 / 8173 - / 1022
25000us 77648 / 78669 72539 / 73561 64366 / 65388 63344 / 62322 49041 / 48019 14304 / 4087
50000us 77648 / 78669 74583 / 75604 67431 / 68453 64366 / 65388 54149 / 50062 14304 / 5108
75000us 77648 / 78669 74583 / 75604 69474 / 70496 66409 / 67431 56192 / 53127 14304 / 5108
100000us 77648 / 78669 74583 / 75604 70496 / 71518 67431 / 68453 58236 / 57214 14304 / 8173
200000us 79691 / 80713 76626 / 77648 72539 / 73561 70496 / 71518 64366 / 65388 43932 / 40867
500000us 80713 / 81734 78669 / 79691 76626 / 77648 75604 / 76626 73561 / 71518 64366 / 65388
1000000us 81734 / - 80713 / 81734 78669 / 79691 78669 / 79691 78669 / 77648 74583 / 75604
Number of probes
Probes jOPS / Total jOPS
Request Mix Accuracy
Request Mix Accuracy
Note
(Actual % in the Mix - Expected % in the Mix) must be within:
'Main Tx' limit of +/-5.0% for the requests whose expected % in the mix is >= 10.0%
'Minor Tx' limit of +/-1.0% for the requests whose expected % in the mix is < 10.0%
Rate of Non-Critical Failures
There were no non-critical failures in Response Time curve building
Delay between performance status pings during RT Curve (Response-Throughput Curve)
Delay between status pings
IR/PR Accuracy
IR/PR Accuracy
Run Properties
This section lists properties only set by user
Property Name Default Controller
specjbb.comm.connect.selector.runner.count 0 2
specjbb.comm.connect.timeouts.connect 60000 7000000
specjbb.comm.connect.timeouts.read 60000 6000000
specjbb.comm.connect.timeouts.write 60000 6000000
specjbb.group.count 1 1
specjbb.heartbeat.threshold 100000 10000000
specjbb.txi.pergroup.count 1 1
View table in csv format
Validation Details
Validation Reports

Level: COMPLIANCE
Check Agent Result
Check properties on compliance All PASSED

Level: CORRECTNESS
Check Agent Result
Compare SM and HQ Inventory All PASSED
Other Checks
High-bound (max attempted) is 102168 IR
High-bound (settled) is 88351 IR
