SPECjbb2005 SPECjbb2005 bops = 1889298, SPECjbb2005 bops/JVM = 118081
IBM Corporation IBM Power 730 Express (4.2 GHz, 16 core)
IBM Corporation JRE 1.7.0 (32-bit) IBM J9 2.6 AIX [build pap3270sr3-20120319_01(SR3)]

JVM run JVM Scores
1117152
2118034
3117928
4116659
5118305
6117246
7118209
8118672
9117799
10118772
11118121
12118597
13117725
14118121
15119011
16118947
SPECjbb2005 bops = 1889298, SPECjbb2005 bops/JVM = 118081

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM Power 730 Express (4.2 GHz, 16 core)
Processor POWER7+ (Intelligent Energy Optimization enabled, up to 4540 MHz)
MHz 4228
# of Chips 2
# of Cores 16
# of Cores/Chip 8
HW Threading Enabled? Yes
Procs Avail to Java 64
Memory (MB) 131072
Memory Details 16 x 8 GB DDR3 1066 MHz
Primary cache 32 KBI + 32 KBD on chip per core
Secondary cache 256 KB I+D on chip per core
Other cache 10 MB I+D on chip per core
Filesystem AIX/JFS2
Disks 1 x 177 GB Raid0 SFF-1 SSD
Other hardware
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version JRE 1.7.0 (32-bit) IBM J9 2.6 AIX [build pap3270sr3-20120319_01(SR3)]
JVM Command Line execrset -c processor_set_number -e java -Xlp -Xgcpolicy:gencon -Xms2560m -Xmx2560m -Xmn2048m -Xaggressive -XtlhPrefetch -XlockReservation -Xgcthreads4 spec.jbb.JBBmain -propfile SPECjbb.props
JVM Initial Heap Memory (MB) 2560
JVM Maximum Heap Memory (MB) 2560
JVM Address bits 32
JVM CLASSPATH jbb.jar:
check.jar
JVM BOOTCLASSPATH /speclocal/sdk/jre/lib/ppc/default/jclSC170/vm.jar:
/speclocal/sdk/jre/lib/se-service.jar:
/speclocal/sdk/jre/lib/math.jar:
/speclocal/sdk/jre/lib/jlm.jar:
/speclocal/sdk/jre/lib/ibmorb.jar:
/speclocal/sdk/jre/lib/ibmorbapi.jar:
/speclocal/sdk/jre/lib/ibmcfw.jar:
/speclocal/sdk/jre/lib/ibmpkcs.jar:
/speclocal/sdk/jre/lib/ibmcertpathfw.jar:
/speclocal/sdk/jre/lib/ibmjgssfw.jar:
/speclocal/sdk/jre/lib/ibmjssefw.jar:
/speclocal/sdk/jre/lib/ibmsaslfw.jar:
/speclocal/sdk/jre/lib/ibmjcefw.jar:
/speclocal/sdk/jre/lib/ibmjgssprovider.jar:
/speclocal/sdk/jre/lib/ibmjsseprovider2.jar:
/speclocal/sdk/jre/lib/ibmcertpathprovider.jar:
/speclocal/sdk/jre/lib/xmldsigfw.jar:
/speclocal/sdk/jre/lib/xml.jar:
/speclocal/sdk/jre/lib/charsets.jar:
/speclocal/sdk/jre/lib/resources.jar:
/speclocal/sdk/jre/lib/rt.jar
OS Version IBM AIX V7.1 TL2 SP2
Other software
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location Austin, TX
Test date Jan 14, 2013
H/w available Feb-2013
JVM available Nov-2012
OS available Feb-2013
Other s/w available
AOT Compilation

Tuning
Operating system tunings
  • dscrctl -n -s 1
  • MEMORY_AFFINITY=MCM
Platform tunings
  • The "Dynamic Power Saver - Favor Performance" mode was enabled on "IBM Advanced System Management"
Notes
  • 5120 16 MB large pages defined with vmo command
  • 16 JVMs were run in processor sets each containing 1 core

JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43573
2 86237
3 107788
4 121840 *
5 119361 *
6 116856 *
7 114843 *
8 112862 *
SPECjbb2005 (from 4 to 8) 117152 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43699
2 85144
3 108267
4 122156 *
5 120292 *
6 118255 *
7 115759 *
8 113707 *
SPECjbb2005 (from 4 to 8) 118034 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42695
2 83034
3 107177
4 122290 *
5 120293 *
6 117844 *
7 115530 *
8 113684 *
SPECjbb2005 (from 4 to 8) 117928 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40359
2 82908
3 107308
4 121112 *
5 118986 *
6 116598 *
7 114380 *
8 112220 *
SPECjbb2005 (from 4 to 8) 116659 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 50926
2 90985
3 108757
4 122613 *
5 120561 *
6 118189 *
7 116117 *
8 114042 *
SPECjbb2005 (from 4 to 8) 118305 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41084
2 83788
3 106607
4 122045 *
5 119404 *
6 117091 *
7 114522 *
8 113168 *
SPECjbb2005 (from 4 to 8) 117246 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44972
2 86719
3 108665
4 122896 *
5 120458 *
6 118047 *
7 115686 *
8 113960 *
SPECjbb2005 (from 4 to 8) 118209 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 46903
2 86390
3 109020
4 122862 *
5 121119 *
6 118604 *
7 116278 *
8 114496 *
SPECjbb2005 (from 4 to 8) 118672 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 39829
2 85435
3 108486
4 122047 *
5 119898 *
6 117906 *
7 115533 *
8 113612 *
SPECjbb2005 (from 4 to 8) 117799 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44671
2 95958
3 108989
4 123529 *
5 121099 *
6 118684 *
7 116270 *
8 114279 *
SPECjbb2005 (from 4 to 8) 118772 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38313
2 84474
3 107759
4 122406 *
5 120951 *
6 118105 *
7 115615 *
8 113527 *
SPECjbb2005 (from 4 to 8) 118121 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43803
2 85179
3 108595
4 122937 *
5 120901 *
6 118617 *
7 116372 *
8 114158 *
SPECjbb2005 (from 4 to 8) 118597 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42561
2 84917
3 108585
4 122134 *
5 119928 *
6 117943 *
7 115221 *
8 113399 *
SPECjbb2005 (from 4 to 8) 117725 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43933
2 93516
3 107883
4 122621 *
5 120427 *
6 118227 *
7 115587 *
8 113745 *
SPECjbb2005 (from 4 to 8) 118121 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42534
2 85928
3 109775
4 123311 *
5 121045 *
6 119082 *
7 116941 *
8 114678 *
SPECjbb2005 (from 4 to 8) 119011 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013

JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41697
2 87813
3 109138
4 122938 *
5 121161 *
6 119014 *
7 116816 *
8 114805 *
SPECjbb2005 (from 4 to 8) 118947 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 14, 2013
SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 20-Feb-2013
