Hardware |
|---|
| Hardware Vendor |
Huawei Company |
| Vendor URL |
http://www.huawei.com |
| Model |
Tecal BH620V2 Blade Server |
| Processor |
Intel Xeon E5-2470 (Intel Turbo Boost Technology up to 3.1 GHz) |
| MHz |
2300 |
| # of Chips |
2 |
| # of Cores |
16 |
| # of Cores/Chip |
8 |
| HW Threading Enabled? |
Yes |
| Procs Avail to Java |
32 |
| Memory (MB) |
98304 |
| Memory Details |
12 x 8 GB 2Rx4 PC3-12800R-11, ECC |
| Primary cache |
32 KB I + 32 KB D on chip per core |
| Secondary cache |
256 KB I+D on chip per core |
| Other cache |
20 MB I+D on chip per chip |
| Filesystem |
NTFS |
| Disks |
1 x 160GB SSD 2.5" SATA, Huawei P/N 02310KSX |
| Other hardware |
Tecal E6000H Blade Server Chassis, 2x NX110 GE switching modules,2 independent management modules, 9 hot-swappable fan modules, and 6 x 1600W AC PSUs |
|
|
Software |
|---|
| Software Vendor |
IBM |
| Vendor URL |
http://www.ibm.com |
| JVM Version |
IBM J9 VM (build 2.6, JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120322_106209 (JIT enabled, AOT enabled) |
| JVM Command Line |
-Xaggressive -Xcompressedrefs -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -Xconcurrentlevel0 |
| JVM Initial Heap Memory (MB) |
1875 |
| JVM Maximum Heap Memory (MB) |
1875 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
C:\jre\lib\jre\lib\aggressive.jar;
C:\jre\lib\jre\bin\compressedrefs\jclSC170\vm.jar;
C:\jre\lib\jre\lib\se-service.jar;
C:\jre\lib\jre\lib\math.jar;
C:\jre\lib\jre\lib\jlm.jar;
C:\jre\lib\jre\lib\ibmorb.jar;
C:\jre\lib\jre\lib\ibmorbapi.jar;
C:\jre\lib\jre\lib\ibmcfw.jar;
C:\jre\lib\jre\lib\ibmpkcs.jar;
C:\jre\lib\jre\lib\ibmcertpathfw.jar |
| OS Version |
Microsoft Windows Server 2008 Enterprise x64 Edition R2 SP1 |
| Other software |
N/A |
|
|
Test Information |
|---|
| Tested by |
Huawei |
| SPEC license # |
3175 |
| Test location |
ShenZhen, China |
| Test date |
Feb 23, 2012 |
| H/w available |
Apr-2012 |
| JVM available |
Jun-2012 |
| OS available |
Feb-2011 |
| Other s/w available |
N/A |
|
|
Tuning |
|---|
Operating system tunings- "Lock pages in memory" was enabled for the user running the benchmark
- start /affinity [F, F0, F00, F000, F0000, F00000, F000000, F0000000]
|
|
Notes |
|---|
- Command line options are described at: http://publib.boulder.ibm.com/infocenter/java7sdk/v7r0/index.jsp
|
|
