Hardware |
|---|
| Hardware Vendor |
Hewlett-Packard Company |
| Vendor URL |
http://www.hp.com |
| Model |
ProLiant BL660c Gen8 |
| Processor |
Intel Xeon E5-4650 (Intel Turbo Boost Technology up to 3.30 GHz) |
| MHz |
2700 |
| # of Chips |
4 |
| # of Cores |
32 |
| # of Cores/Chip |
8 |
| HW Threading Enabled? |
Yes |
| Procs Avail to Java |
64 |
| Memory (MB) |
262144 |
| Memory Details |
256 GB (32 x 8 GB 2Rx4 PC3-12800R-11, ECC) |
| Primary cache |
32 KB I + 32 KB D on chip per core |
| Secondary cache |
256 KB I+D on chip per core |
| Other cache |
20 MB I+D on chip per chip |
| Filesystem |
NTFS |
| Disks |
2 x 146 GB 15 K SAS, RAID 1 |
| Other hardware |
N/A |
|
|
Software |
|---|
| Software Vendor |
Oracle Corporation |
| Vendor URL |
http://www.oracle.com |
| JVM Version |
Oracle Java HotSpot(TM) 64-bit Server VM on Windows, version 1.6.0_30 |
| JVM Command Line |
\java\bin\java.exe -server -Xmx29g -Xms29g -Xmn24g -XX:SurvivorRatio=60 -XX:TargetSurvivorRatio=90 -XX:ParallelGCThreads=32 -XX:BiasedLockingStartupDelay=200 -XX:-UseAdaptiveSizePolicy -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:+UseLargePages -XX:+UseParallelOldGC -XX:+UseCompressedStrings -XX:+AggressiveOpts spec.jbb.JBBmain -propfile SPECjbb.props4 -id 1 |
| JVM Initial Heap Memory (MB) |
29696 |
| JVM Maximum Heap Memory (MB) |
29696 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar |
| JVM BOOTCLASSPATH |
c:\java\lib\alt-string.jar;
c:\java\lib\alt-rt.jar;
c:\java\lib\resources.jar;
c:\java\lib\rt.jar;
c:\java\lib\sunrsasign.jar;
c:\java\lib\jsse.jar;
c:\java\lib\jce.jar;
c:\java\lib\charsets.jar;
c:\java\lib\modules\jdk.boot.jar;
c:\java\classes |
| OS Version |
Microsoft Windows Server 2008 R2, SP1 Enterprise, x64 |
| Other software |
HP Service Pack for ProLiant SSP2012060B.2012.1.iso (unattended installation) |
|
|
Test Information |
|---|
| Tested by |
Hewlett-Packard Company |
| SPEC license # |
3 |
| Test location |
Houston, TX |
| Test date |
Aug 7, 2012 |
| H/w available |
Sept-2012 |
| JVM available |
Dec-2011 |
| OS available |
Feb-2011 |
| Other s/w available |
Mar-2012 |
|
|
Tuning |
|---|
- Used "start /AFFINITY 0xFFFF, 0xFFFF0000, 0xFFFF00000000, 0xFFFF000000000000"
- "Lock pages in memory" enabled for benchmark user.
- Set input.expected_peak_warehouse to 16 due to a known inconsistency in processor reporting with the Java used.
|
|
Notes |
|---|
- Command line options are described at: http://www.oracle.com/technetwork/java/javase/tech/vmoptions-jsp-140102.html
- Each JVM instance had the affinity mask set to bind to 16 logical cores each, 4 JVMs total.
- BIOS Configuration:
- Power Profile set to Maximum Performance
- Thermal Configuration set to Maximum Cooling
- HW Prefetcher set to Disabled
- Adjacent Sector Prefetcher set to Disabled
- DCU Streamer Prefetcher set to Disabled
- Collaborative Power Control set to Disabled
- Processor Power and Utilization Monitoring set to Disabled
- Dynamic Power Capping Functionality set to Disabled
|
|
