SPECjbb

SPECjbb2005		SPECjbb2005 bops = 1274135, SPECjbb2005 bops/JVM = 79633
Dell Inc. PowerEdge R715 (AMD Opteron 6282 SE, 2.60 GHz)
IBM Corporation IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa64 60sr5-20090519_35743 (JIT enabled, AOT enabled)

JVM run JVM Scores

1 80050

2 79479

3 80011

4 79488

5 79986

6 79800

7 80235

8 80219

9 78431

10 79307

11 78930

12 79332

13 79348

14 80480

15 79247

16 79792

SPECjbb2005 bops = 1274135, SPECjbb2005 bops/JVM = 79633

Hardware

Hardware Vendor Dell Inc.

Vendor URL http://www.dell.com

Model PowerEdge R715 (AMD Opteron 6282 SE, 2.60 GHz)

Processor AMD Opteron 6282 SE (AMD Turbo Core up to 3.3 GHz)

MHz 2600

# of Chips 2

# of Cores 32

# of Cores/Chip 16

HW Threading Enabled? No

Procs Avail to Java 32

Memory (MB) 131072

Memory Details 16 x 8GB 2Rx8 PC3L-12800R-11, ECC

Primary cache 512 KB I + 256 KB D on chip per chip, 64 KB I shared / 2 cores, 16 KB D per core

Secondary cache 16 MB I+D on chip per chip, 2 MB shared / 2 cores

Other cache 16 MB I+D L3 on chip per chip, 8 MB shared / 8 cores

Filesystem NTFS

Disks 2 x 160 GB 15k SAS (classes + OS)

Other hardware N/A

Software

Software Vendor IBM Corporation

Vendor URL http://www.IBM.com

JVM Version IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa64 60sr5-20090519_35743 (JIT enabled, AOT enabled)

JVM Command Line start /high /affinity [3,C,30,C0,300,C00,3000,C000,30000,C0000,300000,C00000,3000000,C000000,30000000,C0000000] -Xmn1400m -Xms1875m -Xmx1875m -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -XlockReservation -Xnoloa -XtlhPrefetch -Xlp

JVM Initial Heap Memory (MB) 1875

JVM Maximum Heap Memory (MB) 1875

JVM Address bits 64

JVM CLASSPATH .\jbb.jar;
.\check.jar;

JVM BOOTCLASSPATH c:\specjbb2005\jvm\jre\bin\compressedrefs\jclSC160\vm.jar;
c:\specjbb2005\jvm\jre\lib\annotation.jar;
c:\specjbb2005\jvm\jre\lib\beans.jar;
c:\specjbb2005\jvm\jre\lib\java.util.jar;
c:\specjbb2005\jvm\jre\lib\jndi.jar;
c:\specjbb2005\jvm\jre\lib\logging.jar;
c:\specjbb2005\jvm\jre\lib\security.jar;
c:\specjbb2005\jvm\jre\lib\sql.jar;
c:\specjbb2005\jvm\jre\lib\ibmorb.jar;
c:\specjbb2005\jvm\jre\lib\ibmorbapi.jar;
c:\specjbb2005\jvm\jre\lib\ibmcfw.jar;
c:\specjbb2005\jvm\jre\lib\rt.jar;
c:\specjbb2005\jvm\jre\lib\charsets.jar;
c:\specjbb2005\jvm\jre\lib\resources.jar;
c:\specjbb2005\jvm\jre\lib\ibmpkcs.jar;
c:\specjbb2005\jvm\jre\lib\ibmcertpathfw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjgssfw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjssefw.jar;
c:\specjbb2005\jvm\jre\lib\ibmsaslfw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjcefw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjgssprovider.jar;
c:\specjbb2005\jvm\jre\lib\ibmjsseprovider2.jar;
c:\specjbb2005\jvm\jre\lib\ibmcertpathprovider.jar;
c:\specjbb2005\jvm\jre\lib\ibmxmlcrypto.jar;
c:\specjbb2005\jvm\jre\lib\management-agent.jar;
c:\specjbb2005\jvm\jre\lib\xml.jar;
c:\specjbb2005\jvm\jre\lib\jlm.jar;
c:\specjbb2005\jvm\jre\lib\javascript.jar

OS Version Microsoft Windows Server 2008 Enterprise x64 Edition R2 SP1

Other software IBM Websphere application server V7.0 for Windows on X86-64bit.

Test Information

Tested by Dell Inc.

SPEC license # 55

Test location Austin, TX

Test date Nov 2, 2011

H/w available Nov-2011

JVM available Jul-2009

OS available Feb-2011

Other s/w available NA

AOT Compilation

None

Tuning

Operating system tunings
'Lock pages in memory' enabled for benchmark user
Each JVM instance was affinitized to 4 cores
BIOS Tunings
'Power Management' set to 'Maximum Performance' in BIOS

Notes

"Notes here"

JVM 1 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38400
2	79284	*
3	80456	*
4	80410	*
5	80293
6	79504
7	79034
8	78754
SPECjbb2005	(from 2 to 4)	80050 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 2 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37612
2	78631	*
3	80030	*
4	79778	*
5	79609
6	79082
7	78394
8	78137
SPECjbb2005	(from 2 to 4)	79479 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 3 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38917
2	79130	*
3	80540	*
4	80363	*
5	79805
6	79368
7	79020
8	79254
SPECjbb2005	(from 2 to 4)	80011 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 4 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37109
2	79017	*
3	79951	*
4	79496	*
5	79574
6	78632
7	78374
8	77973
SPECjbb2005	(from 2 to 4)	79488 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 5 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38801
2	79337	*
3	80584	*
4	80035	*
5	79462
6	78836
7	78529
8	78641
SPECjbb2005	(from 2 to 4)	79986 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 6 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38239
2	78624	*
3	80687	*
4	80087	*
5	79685
6	79479
7	79130
8	78558
SPECjbb2005	(from 2 to 4)	79800 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 7 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	39445
2	79368	*
3	80850	*
4	80488	*
5	80375
6	79539
7	79348
8	78842
SPECjbb2005	(from 2 to 4)	80235 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 8 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37994
2	80125	*
3	80628	*
4	79905	*
5	80326
6	79472
7	79380
8	78942
SPECjbb2005	(from 2 to 4)	80219 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 9 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	40398
2	77623	*
3	79069	*
4	78602	*
5	78633
6	77921
7	77532
8	77075
SPECjbb2005	(from 2 to 4)	78431 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 10 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37469
2	78419	*
3	80082	*
4	79419	*
5	79247
6	78958
7	78500
8	78072
SPECjbb2005	(from 2 to 4)	79307 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 11 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37910
2	77880	*
3	79469	*
4	79442	*
5	78770
6	78177
7	78078
8	77230
SPECjbb2005	(from 2 to 4)	78930 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 12 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38103
2	78931	*
3	79710	*
4	79355	*
5	78645
6	78068
7	78306
8	77833
SPECjbb2005	(from 2 to 4)	79332 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 13 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38841
2	78709	*
3	80192	*
4	79143	*
5	79266
6	78338
7	78218
8	78153
SPECjbb2005	(from 2 to 4)	79348 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 14 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38386
2	79887	*
3	80980	*
4	80574	*
5	80390
6	79501
7	78802
8	78518
SPECjbb2005	(from 2 to 4)	80480 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 15 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37572
2	78889	*
3	79578	*
4	79274	*
5	79273
6	78657
7	77752
8	77765
SPECjbb2005	(from 2 to 4)	79247 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011

JVM 16 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38101
2	78583	*
3	80608	*
4	80187	*
5	79831
6	79346
7	79006
8	79052
SPECjbb2005	(from 2 to 4)	79792 SPECjbb2005 bops

SPEC license # 55

Tested by: Dell Inc.

Test date: Nov 2, 2011
