SPECjbb2005 SPECjbb2005 bops = 2582363, SPECjbb2005 bops/JVM = 129118
IBM Corporation IBM System x3850 X5
IBM Corporation IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090326_01(SR5) (JIT enabled, AOT enabled)

JVM run JVM Scores
1129566
2129085
3127979
4127114
5129419
6128424
7128637
8129500
9127778
10129099
11127384
12129900
13130104
14128226
15128999
16130923
17129974
18129814
19129929
20130509
SPECjbb2005 bops = 2582363, SPECjbb2005 bops/JVM = 129118

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM System x3850 X5
Processor Intel Xeon E7-4870
MHz 2400
# of Chips 4
# of Cores 40
# of Cores/Chip 10
HW Threading Enabled? Yes
Procs Avail to Java 80
Memory (MB) 524288
Memory Details 64 x 8GB, 4Rx8 PC3L-8500R
Primary cache 32KBI+32KBD
Secondary cache 256KB(I+D) on chip per chip
Other cache 30 MB per processor
Filesystem NTFS
Disks 1 x 50GB SATA SSD
Other hardware
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090326_01(SR5) (JIT enabled, AOT enabled)
JVM Command Line start /NODE %NODE% /AFFINITY %HEX% java -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1500m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp spec.jbb.JBBmain -propfile SPECjbb.props
JVM Initial Heap Memory (MB) 1875
JVM Maximum Heap Memory (MB) 1875
JVM Address bits 64
JVM CLASSPATH .\jbb.jar;
.\check.jar;
JVM BOOTCLASSPATH C:\Program Files\IBM\Java60\jre\bin\compressedrefs\jclSC160\vm.jar;
C:\Program Files\IBM\Java60\jre\lib\annotation.jar;
C:\Program Files\IBM\Java60\jre\lib\beans.jar;
C:\Program Files\IBM\Java60\jre\lib\java.util.jar;
C:\Program Files\IBM\Java60\jre\lib\jndi.jar;
C:\Program Files\IBM\Java60\jre\lib\logging.jar;
C:\Program Files\IBM\Java60\jre\lib\security.jar;
C:\Program Files\IBM\Java60\jre\lib\sql.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmorb.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmorbapi.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmcfw.jar;
C:\Program Files\IBM\Java60\jre\lib\rt.jar;
C:\Program Files\IBM\Java60\jre\lib\charsets.jar;
C:\Program Files\IBM\Java60\jre\lib\resources.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmpkcs.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmcertpathfw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjgssfw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjssefw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmsaslfw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjcefw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjgssprovider.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjsseprovider2.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmcertpathprovider.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmxmlcrypto.jar;
C:\Program Files\IBM\Java60\jre\lib\management-agent.jar;
C:\Program Files\IBM\Java60\jre\lib\xml.jar;
C:\Program Files\IBM\Java60\jre\lib\jlm.jar;
C:\Program Files\IBM\Java60\jre\lib\javascript.jar
OS Version Microsoft Windows Server 2008 Enterprise x64 Edition R2
Other software Microsoft KB2028687-x64
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location RTP, NC
Test date Mar 22, 2011
H/w available May-2011
JVM available Jun-2009
OS available Oct-2009
Other s/w available Sep-2010
AOT Compilation

precompiled code for

  • Deliverytransaction.process
  • TransactionManager.go
loaded at startup

Tuning
Operating system tunings
  • Node Mask set to 0, 1, 2, 3
  • For each Node Mask value the Affinity Masks were set to 0xF, 0xF0, 0xF00, 0xF000, 0xF0000
  • Lock Pages in memory enabled under Local Security Policies
BIOS Settings
  • Operating Mode set to Custom Mode
  • Turbo Mode Enabled
  • Turbo Boost Power set to Traditional
  • Cache Data Prefetch Disabled
Notes
Set input.expected_peak_warehouse to 4, this is due to the fact that Runtime.getRuntime.availableProcessors() doesn't return the total number of processors in the system but instead returns the number of processors in the group which command prompt belongs to on Windows 2008 R2.

JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44260
2 98636
3 117822
4 131220 *
5 129392 *
6 129556 *
7 129276 *
8 128386 *
SPECjbb2005 (from 4 to 8) 129566 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41901
2 100986
3 113068
4 131171 *
5 130162 *
6 129078 *
7 127588 *
8 127429 *
SPECjbb2005 (from 4 to 8) 129085 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41816
2 98635
3 114831
4 129701 *
5 128643 *
6 127959 *
7 127307 *
8 126284 *
SPECjbb2005 (from 4 to 8) 127979 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42861
2 98621
3 108653
4 128647 *
5 127811 *
6 127405 *
7 125899 *
8 125810 *
SPECjbb2005 (from 4 to 8) 127114 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41727
2 99369
3 116163
4 130532 *
5 130568 *
6 129481 *
7 128879 *
8 127632 *
SPECjbb2005 (from 4 to 8) 129419 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41926
2 100152
3 112611
4 130124 *
5 128038 *
6 128866 *
7 127356 *
8 127738 *
SPECjbb2005 (from 4 to 8) 128424 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41531
2 99221
3 113006
4 130188 *
5 128485 *
6 128610 *
7 127950 *
8 127952 *
SPECjbb2005 (from 4 to 8) 128637 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43104
2 95907
3 111760
4 129866 *
5 130204 *
6 129720 *
7 129056 *
8 128654 *
SPECjbb2005 (from 4 to 8) 129500 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41691
2 97478
3 113209
4 129902 *
5 128558 *
6 127650 *
7 127165 *
8 125617 *
SPECjbb2005 (from 4 to 8) 127778 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41946
2 99390
3 112725
4 130467 *
5 130116 *
6 129052 *
7 128482 *
8 127378 *
SPECjbb2005 (from 4 to 8) 129099 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44434
2 97740
3 112633
4 129313 *
5 128098 *
6 127593 *
7 126354 *
8 125559 *
SPECjbb2005 (from 4 to 8) 127384 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 45114
2 100969
3 113469
4 131592 *
5 130883 *
6 129940 *
7 128376 *
8 128710 *
SPECjbb2005 (from 4 to 8) 129900 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40721
2 100186
3 116628
4 132307 *
5 131311 *
6 129660 *
7 129027 *
8 128214 *
SPECjbb2005 (from 4 to 8) 130104 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42209
2 98923
3 112990
4 130295 *
5 128871 *
6 127637 *
7 127725 *
8 126601 *
SPECjbb2005 (from 4 to 8) 128226 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42067
2 99065
3 116102
4 130307 *
5 129482 *
6 129204 *
7 128263 *
8 127742 *
SPECjbb2005 (from 4 to 8) 128999 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42394
2 100298
3 115423
4 132396 *
5 131951 *
6 130376 *
7 130282 *
8 129611 *
SPECjbb2005 (from 4 to 8) 130923 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 17 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41628
2 97450
3 113575
4 130698 *
5 130961 *
6 130062 *
7 129352 *
8 128796 *
SPECjbb2005 (from 4 to 8) 129974 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 18 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41025
2 97798
3 117563
4 131765 *
5 129926 *
6 129144 *
7 128778 *
8 129456 *
SPECjbb2005 (from 4 to 8) 129814 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 19 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42278
2 98195
3 112699
4 130366 *
5 130279 *
6 130658 *
7 129849 *
8 128494 *
SPECjbb2005 (from 4 to 8) 129929 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011

JVM 20 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43880
2 102305
3 115442
4 132216 *
5 130672 *
6 130890 *
7 129449 *
8 129319 *
SPECjbb2005 (from 4 to 8) 130509 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 22, 2011
SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 20-Apr-2011
