Hardware |
|---|
| Hardware Vendor |
Dell Inc. |
| Vendor URL |
http://www.dell.com |
| Model |
PowerEdge R815 (AMD Opteron 6176 SE, 2.30 GHz) |
| Processor |
AMD Opteron 6176 SE |
| MHz |
2300 |
| # of Chips |
2 |
| # of Cores |
24 |
| # of Cores/Chip |
12 |
| HW Threading Enabled? |
No |
| Procs Avail to Java |
24 |
| Memory (MB) |
65536 |
| Memory Details |
16 x 4 GB DDR3-1333 DR RDIMM |
| Primary cache |
64 KB I + 64 KB D on chip per core |
| Secondary cache |
512 KB I+D on chip per core |
| Other cache |
10 MB I+D L3 on chip per chip |
| Filesystem |
NTFS |
| Disks |
1 x 50 GB SSD SATA |
| Other hardware |
N/A |
|
|
Software |
|---|
| Software Vendor |
IBM Corporation |
| Vendor URL |
http://www.ibm.com |
| JVM Version |
IBM J9 VM (build 2.4, JRE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa64 60sr5-20090519_35743 (JIT enabled, AOT enabled) |
| JVM Command Line |
start /HIGH /affinity [3F,FC0,3F000,FC0000] Java -Xmn1400m -Xms1875m -Xmx1875m -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -XlockReservation -Xnoloa -XtlhPrefetch -Xlp spec.jbb.JBBmain -propfile SPECjbb.props |
| JVM Initial Heap Memory (MB) |
1875 |
| JVM Maximum Heap Memory (MB) |
1875 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
c:\specjbb2005\jvm\jre\bin\compressedrefs\jclSC160\vm.jar;
c:\specjbb2005\jvm\jre\lib\annotation.jar;
c:\specjbb2005\jvm\jre\lib\beans.jar;
c:\specjbb2005\jvm\jre\lib\java.util.jar;
c:\specjbb2005\jvm\jre\lib\jndi.jar;
c:\specjbb2005\jvm\jre\lib\logging.jar;
c:\specjbb2005\jvm\jre\lib\security.jar;
c:\specjbb2005\jvm\jre\lib\sql.jar;
c:\specjbb2005\jvm\jre\lib\ibmorb.jar;
c:\specjbb2005\jvm\jre\lib\ibmorbapi.jar;
c:\specjbb2005\jvm\jre\lib\ibmcfw.jar;
c:\specjbb2005\jvm\jre\lib\rt.jar;
c:\specjbb2005\jvm\jre\lib\charsets.jar;
c:\specjbb2005\jvm\jre\lib\resources.jar;
c:\specjbb2005\jvm\jre\lib\ibmpkcs.jar;
c:\specjbb2005\jvm\jre\lib\ibmcertpathfw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjgssfw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjssefw.jar;
c:\specjbb2005\jvm\jre\lib\ibmsaslfw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjcefw.jar;
c:\specjbb2005\jvm\jre\lib\ibmjgssprovider.jar;
c:\specjbb2005\jvm\jre\lib\ibmjsseprovider2.jar;
c:\specjbb2005\jvm\jre\lib\ibmcertpathprovider.jar;
c:\specjbb2005\jvm\jre\lib\ibmxmlcrypto.jar;
c:\specjbb2005\jvm\jre\lib\management-agent.jar;
c:\specjbb2005\jvm\jre\lib\xml.jar;
c:\specjbb2005\jvm\jre\lib\jlm.jar;
c:\specjbb2005\jvm\jre\lib\javascript.jar |
| OS Version |
Microsoft Windows Server 2008 R2 Enterprise Edition |
| Other software |
N/A |
|
|
Test Information |
|---|
| Tested by |
Dell Inc. |
| SPEC license # |
55 |
| Test location |
Round Rock, TX |
| Test date |
Mar 11, 2010 |
| H/w available |
Mar-2010 |
| JVM available |
Jul-2009 |
| OS available |
Oct-2009 |
| Other s/w available |
N/A |
|
|
Tuning |
|---|
- Disabled 'Hardware Prefetcher' in BIOS
- Disabled 'DRAM Prefetcher' in BIOS
- Disabled 'Hardware Prefetch training on Software Prefetch' in BIOS
- 'Power Management' set to 'Maximum Performance' in BIOS
- 'Lock pages in memory' enabled for benchmark user
- Each JVM instance was affinitized to 6 cores
|
|
Notes |
|---|
| Command line options are described at:http://publib.boulder.ibm.com/infocenter/javasdk/v6r0/index.jsp |
|
