Hardware |
|---|
| Hardware Vendor |
Fujitsu Siemens Computers |
| Vendor URL |
http://www.fujitsu-siemens.com |
| Model |
PRIMERGY RX600 S4, Intel Xeon X7460, 2.66 GHz |
| Processor |
Intel Xeon X7460 (2.66 GHz, 3x3MB L2, 1067 MHz system bus) |
| MHz |
2667 |
| # of Chips |
4 |
| # of Cores |
24 |
| # of Cores/Chip |
6 |
| HW Threading Enabled? |
N/A |
| Procs Avail to Java |
24 |
| Memory (MB) |
65536 |
| Memory Details |
16x4GB PC2-5300F (CAS 5-5-5) |
| Primary cache |
32KB(I) + 32KB(D) on chip, per core |
| Secondary cache |
9MB(I+D) on chip, per chip (3MB shared / 2 cores) |
| Other cache |
16MB(I+D) on chip, per chip |
| Filesystem |
NTFS |
| Disks |
Seagate (2.5", SAS, 36GB, 10krpm) |
| Other hardware |
N/A |
|
|
Software |
|---|
| Software Vendor |
Oracle Corporation |
| Vendor URL |
http://www.oracle.com |
| JVM Version |
Oracle JRockit(R) 6 P28.0.0 (build P28.0.0-8-109238-1.6.0_05-20090130-1408-windows-x86_64) |
| JVM Command Line |
start /AFFINITY [0x00003F,0x000FC0,0x03F000,0xFC0000] /B java -Xms3700m -Xmx3700m -Xns2800m -XXaggressive -Xlargepages -Xgc:genpar -XXcallprofiling -XXgcthreads=6 -XXtlasize:min=4k,preferred=1024k -XX:+UseStringCache spec.jbb.JBBmain -propfile SPECjbb.props |
| JVM Initial Heap Memory (MB) |
3700 |
| JVM Maximum Heap Memory (MB) |
3700 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\jrockit1.6.0.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\jmapi.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\jmxmapi.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\rmp.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\latency.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\resources.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\rt.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\sunrsasign.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\jsse.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\jce.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\charsets.jar;
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\classes |
| OS Version |
Microsoft Windows Server 2003 R2 Enterprise x64 Edition |
| Other software |
N/A |
|
|
Test Information |
|---|
| Tested by |
Fujitsu Siemens Computers |
| SPEC license # |
22 |
| Test location |
Paderborn, Germany |
| Test date |
Feb 6, 2009 |
| H/w available |
Oct-2008 |
| JVM available |
May-2009 |
| OS available |
May-2005 |
| Other s/w available |
N/A |
|
|
Tuning |
|---|
- Each JVM instance was affinitized to a socket.
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
|
|
Notes |
|---|
| The Fujitsu Siemens Computers PRIMERGY RX600 S4 and the Fujitsu PRIMERGY RX600 S4 are electronically equivalent. |
|
