SPECjbb

SPECjbb2005		SPECjbb2005 bops = 1001183, SPECjbb2005 bops/JVM = 58893
SGI Altix 4700 (17 Blade/34P DC)
BEA Systems BEA JRockit(R) 5.0 P26.4.0-10 (build P26.4.0-10-62459-1.5.0_06-20060529-2101-linux-ia64)

JVM run JVM Scores

1 58959

2 58864

3 58816

4 58847

5 59008

6 58834

7 58957

8 59087

9 58815

10 58803

11 58832

12 58863

13 58835

14 58789

15 58872

16 59235

17 58767

SPECjbb2005 bops = 1001183, SPECjbb2005 bops/JVM = 58893

Hardware

Hardware Vendor SGI

Vendor URL http://www.sgi.com

Model Altix 4700 (17 Blade/34P DC)

Processor Intel DC Itanium2 Processor 9050 1.6 Ghz

MHz 1600

# of Chips 34

# of Cores 68

# of Cores/Chip 2

HW Threading Enabled? No

Procs Avail to Java 68

Memory (MB) 139264

Memory Details 1 GB ECC DDR2 DIMMs (PC2-3200R) spread uniformly over 17 compute blades

Primary cache 16kBI + 16kBD on chip per core

Secondary cache 1024kBI + 256kBD on chip per core

Other cache 12MB (I+D) on chip per core

Filesystem xfs

Disks 1 x 146 GB SCSI (classes + OS)

Other hardware

Software

Software Vendor BEA Systems

Vendor URL http://www.bea.com

JVM Version BEA JRockit(R) 5.0 P26.4.0-10 (build P26.4.0-10-62459-1.5.0_06-20060529-2101-linux-ia64)

JVM Command Line numactl --cpubind=$node --localalloc java -Xms3840m -Xmx3840m -XXaggressive -XXcompressedRefs -XXthroughputCompaction -XXlazyUnlocking -XXtlasize256k -XXgcthreads8 -cp jbb.jar:check.jar spec.jbb.JBBmain -propfile SPECjbb.props -id $id

JVM Initial Heap Memory (MB) 3840

JVM Maximum Heap Memory (MB) 3840

JVM Address bits 64

JVM CLASSPATH jbb.jar:
check.jar

JVM BOOTCLASSPATH /tmp/jrockit-jdk1.5.0_06/jre/lib/ia64/jrockit/jrockit.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/ia64/jrockit/managementapi.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/managementapi.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/rt.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/i18n.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/sunrsasign.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/jsse.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/jce.jar:
/tmp/jrockit-jdk1.5.0_06/jre/lib/charsets.jar:
/tmp/jrockit-jdk1.5.0_06/jre/classes

OS Version SuSE Linux Enterprise Server 9 SP3 (2.6.5-7.244-sn2)

Other software

Test Information

Tested by SGI

SPEC license # 4

Test location Mountain View, CA

Test date Aug 7, 2006

H/w available July-2006

JVM available June-2006

OS available Jan-2006

Other s/w available

AOT Compilation

Tuning

Operating system tunings
mount -t hugetlbfs nodev /mnt/hugepages
echo 340 > /proc/sys/vm/nr_hugepages

Notes

Command line options are described at http://e-docs.bea.com/jrockit/jrdocs/refman/index.html
System configured to use one JVM per NUMA node (4 cores).

JVM 1 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	8629
2	29323
3	43139
4	59394	*
5	58760	*
6	59593	*
7	58945	*
8	58102	*
SPECjbb2005	(from 4 to 8)	58959 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 2 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	9061
2	29726
3	43721
4	58810	*
5	58784	*
6	59408	*
7	59136	*
8	58184	*
SPECjbb2005	(from 4 to 8)	58864 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 3 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	9506
2	29686
3	43738
4	58752	*
5	58855	*
6	59291	*
7	58984	*
8	58199	*
SPECjbb2005	(from 4 to 8)	58816 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 4 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	8127
2	29618
3	44043
4	59107	*
5	58664	*
6	59557	*
7	58987	*
8	57918	*
SPECjbb2005	(from 4 to 8)	58847 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 5 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	9284
2	29293
3	44021
4	59385	*
5	59314	*
6	59528	*
7	58865	*
8	57950	*
SPECjbb2005	(from 4 to 8)	59008 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 6 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	8222
2	29657
3	43037
4	58936	*
5	59094	*
6	59576	*
7	58751	*
8	57812	*
SPECjbb2005	(from 4 to 8)	58834 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 7 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	9672
2	29863
3	44083
4	59227	*
5	58954	*
6	59635	*
7	58931	*
8	58039	*
SPECjbb2005	(from 4 to 8)	58957 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 8 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	8263
2	29711
3	43166
4	59316	*
5	59200	*
6	59719	*
7	59045	*
8	58153	*
SPECjbb2005	(from 4 to 8)	59087 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 9 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	9527
2	29749
3	43987
4	59039	*
5	58998	*
6	59539	*
7	58578	*
8	57923	*
SPECjbb2005	(from 4 to 8)	58815 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 10 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	9156
2	29671
3	43223
4	58931	*
5	59221	*
6	59508	*
7	58303	*
8	58052	*
SPECjbb2005	(from 4 to 8)	58803 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 11 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	8019
2	29605
3	43356
4	59307	*
5	58757	*
6	59165	*
7	58953	*
8	57980	*
SPECjbb2005	(from 4 to 8)	58832 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 12 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	8139
2	29503
3	43674
4	59375	*
5	58888	*
6	59548	*
7	58558	*
8	57943	*
SPECjbb2005	(from 4 to 8)	58863 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 13 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	7215
2	29581
3	43917
4	58459	*
5	58928	*
6	59679	*
7	58941	*
8	58168	*
SPECjbb2005	(from 4 to 8)	58835 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 14 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	8908
2	29786
3	42978
4	58977	*
5	58561	*
6	59320	*
7	58952	*
8	58135	*
SPECjbb2005	(from 4 to 8)	58789 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 15 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	7886
2	29729
3	43045
4	59146	*
5	58773	*
6	59370	*
7	58932	*
8	58141	*
SPECjbb2005	(from 4 to 8)	58872 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 16 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	7767
2	29927
3	43426
4	59477	*
5	59406	*
6	59648	*
7	59097	*
8	58549	*
SPECjbb2005	(from 4 to 8)	59235 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006

JVM 17 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	7762
2	29550
3	42941
4	58874	*
5	58789	*
6	59239	*
7	58829	*
8	58104	*
SPECjbb2005	(from 4 to 8)	58767 SPECjbb2005 bops

SPEC license # 4

Tested by: SGI

Test date: Aug 7, 2006
