Hardware |
Hardware Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com |
Model |
IBM System x3650 |
Processor |
Intel Xeon Processor 5160 (3.0 GHz) |
MHz |
3000 |
# of Chips |
2 |
# of Cores |
4 |
# of Cores/Chip |
2 |
HW Threading Enabled? |
No |
Procs Avail to Java |
4 |
Memory (MB) |
8192 GB |
Memory Details |
8 x 1024 GB PC2 5300 Fully Buffered DIMMs |
Primary cache |
32KB(I) + 32KB(D) on chip, per core |
Secondary cache |
4096KB(I+D) on chip, shared |
Other cache |
|
Filesystem |
NTFS |
Disks |
1 x 36GB SCSI 15k RPM SAS |
Other hardware |
|
|
Software |
Software Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com |
JVM Version |
IBM 32-bit Runtime Environment for Windows, Java 2 Technology Edition, Version 5.0 (build j9vmwi3224-20060617) |
JVM Command Line |
java -Xlp -Xgcpolicy:gencon -Xms1500m -Xmx1500m -Xmn1250m -Xnoloa -XtlhPrefetch -XlockReservation -Xjvm:perf |
JVM Initial Heap Memory (MB) |
1500 |
JVM Maximum Heap Memory (MB) |
1500 |
JVM Address bits |
32 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
c:\ibm\jre\lib\vm.jar; c:\ibm\jre\lib\core.jar; c:\ibm\jre\lib\charsets.jar; c:\ibm\jre\lib\graphics.jar; c:\ibm\jre\lib\security.jar; c:\ibm\jre\lib\ibmpkcs.jar; c:\ibm\jre\lib\ibmorb.jar; c:\ibm\jre\lib\ibmcfw.jar; c:\ibm\jre\lib\ibmorbapi.jar; c:\ibm\jre\lib\ibmjcefw.jar; c:\ibm\jre\lib\ibmjgssprovider.jar; c:\ibm\jre\lib\ibmjsseprovider2.jar; c:\ibm\jre\lib\ibmjaaslm.jar; c:\ibm\jre\lib\ibmjaasactivelm.jar; c:\ibm\jre\lib\ibmcertpathprovider.jar; c:\ibm\jre\lib\server.jar; c:\ibm\jre\lib\xml.jar |
OS Version |
Windows Server 2003 Enterprise Edition (32-bit) |
Other software |
|
|
Test Information |
Tested by |
IBM Corporation |
SPEC license # |
11 |
Test location |
RTP, NC |
Test date |
Jun 23, 2006 |
H/w available |
Jul-2006 |
JVM available |
Sept-2006 |
OS available |
Apr-2003 |
Other s/w available |
|
|
Tuning |
Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark. |
Notes |
- Disabled 'Hardware Prefetcher' in BIOS
- Disabled 'Adjacent Sector Prefetch' in BIOS
|
|
