SPECjbb

SPECjbb2000		SPECjbb2000 = 136261 ops/s
IBM Corporation IBM eServer OpenPower 720
IBM Corporation J2RE 1.4.2 (32-bit) IBM Linux build cxppc32142-20040917


Warehouses	Ops/s	Incl. in metric
1	24054
2	46233
3	67048
4	85327
5	95534
6	113794
7	126031
8	137875	*
9	137626	*
10	137190	*
11	136448	*
12	136270	*
13	136031	*
14	135373	*
15	134916	*
16	134624	*
SPECjbb2000	(from 8 to 16)	136261 ops/s

SPEC license # 11 Tested by: IBM Corporation Test date: Jan 11, 2005

Hardware

Hardware Vendor IBM Corporation

Vendor URL http://www.ibm.com

Model IBM eServer OpenPower 720

Processor POWER5

MHz 1650 MHz

# of Procs 4 cores, 2 chips, 2 cores/chip (SMT on)

Memory (MB) 4096

Primary cache 64KBI+32KBD (on chip)/core

Secondary cache 1920KB unified (on chip)/chip

Other cache 36MB unified (off chip)/DCM, 2 DCMs in SUT

Filesystem Ext2

Disks 1 x 36GB SCSI

Other hardware

Software

Software Vendor IBM Corporation

Vendor URL http://www.ibm.com

Java Precompiler Version

Java Precompiler Command Line

Java Precompiler Way Of Excluding Classes

JVM Version J2RE 1.4.2 (32-bit) IBM Linux build cxppc32142-20040917

JVM Command Line java -Xlp -Xcompactexlpicitgc -ms3328m -mx3328m -spec.jbb.JBBmain -propfile SPECjbb.props

JVM Initial Heap Memory (MB) 3328

JVM Maximum Heap Memory (MB) 3328

JVM CLASSPATH ./jbb.jar:
./jbb_no_precompile.jar:
./check.jar:
./reporter.jar:

JVM BOOTCLASSPATH /opt/cxppc32142-20040917/jre/lib/core.jar:
/opt/cxppc32142-20040917/jre/lib/graphics.jar:
/opt/cxppc32142-20040917/jre/lib/security.jar:
/opt/cxppc32142-20040917/jre/lib/server.jar:
/opt/cxppc32142-20040917/jre/lib/xml.jar:
/opt/cxppc32142-20040917/jre/lib/charsets.jar:
/opt/cxppc32142-20040917/jre/lib/ibmorbapi.jar:
/opt/cxppc32142-20040917/jre/lib/ibmorb.jar:
/opt/cxppc32142-20040917/jre/lib/ibmjsseprovider.jar:
/opt/cxppc32142-20040917/jre/lib/ibmjssefips.jar:
/opt/cxppc32142-20040917/jre/lib/ibmcertpathprovider.jar:
/opt/cxppc32142-20040917/jre/lib/ibmjcefw.jar:
/opt/cxppc32142-20040917/jre/lib/ibmjgssprovider.jar:
/opt/cxppc32142-20040917/jre/lib/ibmpkcs.jar:
/opt/cxppc32142-20040917/jre/lib/ibmjaaslm.jar

OS Version Red Hat Enterprise Linux AS 4

System state normal

Other software

Test Information

Tested by IBM Corporation

SPEC license # 11

Test location Austin, TX

Test date Jan 11, 2005

H/w available Sep-2004

JVM available Oct-2004

OS available Feb-2005

Other s/w available

Tuning

/proc/sys/vm/nr_hugepages=208
/proc/sys/kernel/shmall=3489660928
/proc/sys/kernel/shmmax=3489660928
selinux=off

Notes

Details of Runs

Warehouses	Thrput	Total heap (MB)		Thread spread %	% > 120s	transaction type	Count	Time (in seconds)
Warehouses	Thrput	Size	Used	Thread spread %	% > 120s	transaction type	Count	total	max
1	24054	3328	33.1	<0.01%	.016	new_order	1255214	66.5	.056
						payment	1255216	25.0	<0.01
						order_status	125522	2.24	<0.01
						delivery	125521	7.24	<0.01
						stock_level	125522	12.9	<0.01
2	46233	3328	54.4	1.02%	.016	new_order	2412522	134	.058
						payment	2412523	49.6	<0.01
						order_status	241251	4.52	<0.01
						delivery	241252	14.7	<0.01
						stock_level	241252	25.8	.058
3	67048	3328	74.8	4.81%	.016	new_order	3498718	201	.063
						payment	3498715	74.5	.059
						order_status	349872	6.78	<0.01
						delivery	349872	22.4	.063
						stock_level	349871	37.9	.060
4	85327	3328	93.5	7.84%	.017	new_order	4452581	268	.067
						payment	4452573	98.4	.064
						order_status	445259	9.05	<0.01
						delivery	445256	29.8	.067
						stock_level	445258	51.8	.067
5	95534	3328	117	11.6%	.017	new_order	4985261	334	.079
						payment	4985253	123	.077
						order_status	498528	11.4	<0.01
						delivery	498526	37.2	.074
						stock_level	498525	66.5	.079
6	113794	3328	137	18.6%	.016	new_order	5938020	399	.087
						payment	5938008	148	.087
						order_status	593800	13.5	<0.01
						delivery	593800	45.6	.082
						stock_level	593800	79.9	.085
7	126031	3328	156	6.14%	.016	new_order	6576585	465	.095
						payment	6576577	172	.092
						order_status	657656	15.7	<0.01
						delivery	657658	53.2	.092
						stock_level	657657	94.9	.095
8	137875	3328	174	1.59%	.016	new_order	7194610	533	.102
						payment	7194608	195	.102
						order_status	719458	17.8	<0.01
						delivery	719461	60.6	.097
						stock_level	719461	108	.102
9	137626	3328	195	18.2%	.019	new_order	7181858	603	.466
						payment	7181866	218	.424
						order_status	718187	19.6	.110
						delivery	718186	68.4	.472
						stock_level	718186	122	.180
10	137190	3328	212	37.8%	.017	new_order	7158991	669	.513
						payment	7158987	244	.499
						order_status	715898	23.3	.101
						delivery	715899	74.9	.300
						stock_level	715898	133	.193
11	136448	3328	229	25.8%	.016	new_order	7120149	734	.513
						payment	7120143	268	.476
						order_status	712014	23.6	.183
						delivery	712014	83.5	.496
						stock_level	712015	148	.207
12	136270	3328	245	40.6%	.017	new_order	7110910	805	.912
						payment	7110912	289	.602
						order_status	711091	26.8	.100
						delivery	711094	90.8	.399
						stock_level	711095	163	.518
13	136031	3328	264	31.5%	.016	new_order	7098364	864	.527
						payment	7098374	325	.585
						order_status	709838	27.9	.133
						delivery	709836	97.3	.294
						stock_level	709835	174	.504
14	135373	3328	280	30.0%	.016	new_order	7064080	931	.561
						payment	7064075	348	.573
						order_status	706410	31.9	.472
						delivery	706408	101	.277
						stock_level	706408	189	.596
15	134916	3328	297	20.6%	.017	new_order	7040281	992	.627
						payment	7040279	369	.601
						order_status	704030	35.5	.189
						delivery	704029	117	.635
						stock_level	704032	203	.634
16	134624	3328	318	26.9%	.017	new_order	7025075	1063	.638
						payment	7025099	391	.587
						order_status	702509	34.3	.200
						delivery	702509	123	.719
						stock_level	702509	215	.727
