SPECjAppServer2004 Result: BEA WebLogic Server 9.0 on HP-UX rx4640

SPECjAppServer®2004 Result
Copyright © 2004 Standard Performance Evaluation Corporation

BEA WebLogic Server 9.0 on HP-UX rx4640

471.28 SPECjAppServer2004 JOPS@Standard

Submitter:
HP

SPEC license # 3

Test date:
Sep-2005

Software Products
BEA WebLogic Server 9.0, Advantage Edition
Java(TM) 2 Runtime Environment, Standard Edition (build 1.5.0.01-_06_jun_2005_05_20) 32 bit
Oracle JDBC Driver 10.1.0.3 (Thin)
Oracle Database 10g Enterprise Edition Release 10.1.0.4

Software Configurations
J2EE Application Servers
Emulator SW Config
Database SW Config
Driver SW Config Primary

Hardware Systems
J2EE AppServer HW
Database Server HW
Load Driver HW

System Configuration Diagram

Benchmark
Modifications
Configuration
Bill of Materials
Other Info
General Notes
Full Disclosure Archive

SUT Configuration

J2EE Server Nodes:	1	DB Server Nodes:	1
J2EE Server CPUs:	4 cores, 4 chips	DB Server CPUs:	4 cores, 4 chips
J2EE Instances:	4	DB Instances:	1

Other SUT Components:
None.

Benchmark Settings

Dealer Injection Rate:	284	Ramp Up Time:	600 seconds
# of Dealer Agents:	4	Ramp Down Time:	300 seconds
# of Manufacturing Agents:	3	Steady State Time:	3,600 seconds
DB Load Injection Rate:	300	Trigger Time:	900 seconds

Detailed Results

Dealer Transaction Mix	Count	Tx. Mix
Purchase	256,436	25.00%
Manage	256,476	25.00%
Browse	512,915	50.00%
Total # Dealer Transactions	1,025,827

Total # Manufacturing Transactions	670,765

Response Times	Average	Maximum	90th%	Reqd
Purchase	0.14	10.28	0.40	2.00
Manage	0.15	8.92	0.40	2.00
Browse	0.17	12.01	0.50	2.00
Manufacturing	2.21	13.45	4.25	5.00

Reproducibility Run (SPECjAppServer2004 JOPS)	471.34

BEA WebLogic Server 9.0, Advantage Edition

Vendor:	BEA Systems, Inc.	Availability:	Oct-2005
CTS Version:	1.4	Date Passed CTS:	Jun-2005
OS Name:	HP-UX 11i version 2 9/04 patch
EJB Protocol:	RMI/T3

Java(TM) 2 Runtime Environment, Standard Edition (build 1.5.0.01-_06_jun_2005_05_20) 32 bit

Vendor:	HP	Availability:	Jul-2005
OS Name:	HP-UX 11i version 2 9/04 patch

Oracle JDBC Driver 10.1.0.3 (Thin)

Vendor:	Oracle Corporation	Availability:	Aug-2004
OS Name:	HP-UX 11i version 2 9/04 patch

Oracle Database 10g Enterprise Edition Release 10.1.0.4

Vendor:	Oracle Corporation	Availability:	May-2005
OS Name:	HP-UX 11i version 2 9/04 patch

J2EE Application Servers

J2EE Product:	BEA WebLogic Server 9.0, Advantage Edition
JVM Product:	Java(TM) 2 Runtime Environment, Standard Edition (build 1.5.0.01-_06_jun_2005_05_20) 32 bit
JDBC Product:	Oracle JDBC Driver 10.1.0.3 (Thin)
Hardware:	J2EE AppServer HW
# of Instances:	4
Interfaces:
	Web Interface for the Dealer Domain
	Web Interface for the Supplier Domain
	EJB Interface for the Dealer Domain
	EJB Interface for the Manufacturing Domain
	EJB Interface for the Supplier Domain

Notes / Tuning Information

-XX:+AggressiveHeap -Xmx2000m -Xms2000m -Xmn1000m -Xoptgc
-Xverbosegc:file=stdout -XX:+ForceMmapReserved -XX:PermSize=96m
-XX:SurvivorRatio=14 -XX:-UseHighResolutionTimer -XX:-StackTraceInThrowable
-XX:SchedulerPriorityRange=SCHED_RTPRIO -XX:TLABSize=32k
-XX:-UseFastAccessorMethods

Emulator SW Config

JVM Product:	Java(TM) 2 Runtime Environment, Standard Edition (build 1.5.0.01-_06_jun_2005_05_20) 32 bit
Web Product:	BEA WebLogic Server 9.0, Advantage Edition
Hardware:	Load Driver HW
# of Instances:	1

Notes / Tuning Information
-Xmx1000m -Xms1000m -Xmn128m -Xoptgc -XX:-UseBoundThreads -XX:+ForceMmapReserved -XX:PermSize=64m -XX:SurvivorRatio=20 -XX:-UseHighResolutionTimer -XX:-StackTraceInThrowable

Database SW Config

DB Product:	Oracle Database 10g Enterprise Edition Release 10.1.0.4
Hardware:	Database Server HW
# of Instances:	1

Notes / Tuning Information

Oracle tuning in init.ora:
_collect_undo_stats=FALSE
_db_block_hash_latches=4096
_db_cache_pre_warm=FALSE
_db_writer_flush_imu=FALSE
_enable_NUMA_optimization=FALSE
_imu_pools=500
_smm_advice_enabled=FALSE
_two_pass=FALSE
_undo_autotune=FALSE
aq_tm_processes=0
compatible=10.1.0.0.0
cursor_space_for_time = TRUE
db_8k_cache_size = 536870912
db_block_checking = FALSE
db_block_checksum = FALSE
db_block_size = 2048
db_cache_advice = OFF
db_cache_size = 5251268608
db_file_multiblock_read_count = 128
db_files = 256
dml_locks = 600
enqueue_resources = 2000
fast_start_mttr_target=0
hpux_sched_noage=178
log_buffer=102400000
log_checkpoint_interval = 0
log_checkpoint_timeout=0
log_checkpoints_to_alert=TRUE
open_cursors = 2000
parallel_max_servers = 100
pga_aggregate_target=0
processes = 600
query_rewrite_enabled=FALSE
replication_dependency_tracking=FALSE
sessions = 800
session_cached_cursors=710
shared_pool_size = 318767104
sort_area_size=52428800
transactions = 800
transactions_per_rollback_segment = 1
trace_enabled=FALSE
undo_management = AUTO
undo_retention = 5
undo_tablespace = undo_ts
timed_statistics = FALSE
statistics_level = basic

log writer put into realtime class with /usr/bin/rtprio 127 -PID

Driver SW Config Primary

JVM Product:	Java(TM) 2 Runtime Environment, Standard Edition (build 1.5.0.01-_06_jun_2005_05_20) 32 bit
Hardware:	Load Driver HW
# of Instances:	1

Notes / Tuning Information

-Xms900M -Xmx900M -Xmn128M -XX:+DisableExplicitGC
-Xoptgc -XX:-UseBoundThreads -XX:+ForceMmapReserved -XX:PermSize=64m
-XX:SurvivorRatio=20 -XX:-UseHighResolutionTimer -XX:-StackTraceInThrowable
-Dsun.net.inetaddr.ttl=0 -Dnetworkaddress.cache.ttl=0
-Dorg.omg.CORBA.ORBInitialHost=$JAS_MULTI_HOST -Djava.naming.factory.initial=$JNDI_CLASS
-Djava.naming.provider.url=$NAMING_PROVIDER

J2EE AppServer HW (SUT hardware)

Hardware Vendor:	HP	OS Vendor:	HP
Model Name:	HP rx4640	OS Name:	HP-UX 11i version 2 9/04 patch
Processor:	Intel Itanium 2	Filesystem:	vxfs
MHz:	1600	Disks:	2x73GB 15K U320
# of CPUs:	4 cores, 4 chips, 1 core/chip	Network Interface:	(1) 1000BaseT Integrated Ethernet
Memory (MB):	16384	Other Hardware:
L1 Cache:	16KB(I)+16KB(D)	# of Systems:	1
L2 Cache:	256KB	H/W Available:	Feb-2004
Other Cache:	9MB (L3 Cache)	OS Available:	Sep-2003

Notes / Tuning Information

Kernel Parameter Changes:

tunable nstrpty 200
tunable create_fastlinks 1
tunable hfs_max_ra_blocks 20
tunable hfs_max_revra_blocks 20
tunable hfs_ra_per_disk 256
tunable hfs_revra_per_disk 256
tunable max_thread_proc 2048
tunable maxssiz 401604608
tunable maxtsiz 1073741824
tunable maxuprc 3277
tunable maxvgs 80
tunable msgmap 5122
tunable msgmax 32768
tunable msgmnb 65536
tunable msgseg 20480
tunable msgssz 128
tunable msgtql 5120
tunable ninode 8192
tunable npty 200
tunable nswapdev 25
tunable semmni 4096
tunable semmns 8192
tunable semmnu 4092
tunable semume 512
tunable shmmni 520
tunable shmseg 512
tunable STRMSGSZ 65535
tunable vps_ceiling 64
tunable dbc_min_pct 5
tunable dbc_max_pct 5
tunable cmc_plat_poll 15
tunable maxdsiz 4294963200
tunable default_disk_ir 1
tunable fs_async 1
tunable max_async_ports 768
tunable o_sync_is_o_dsync 1
tunable shmmax 4200000000
tunable maxfiles_lim 8192
tunable swapmem_on 0
tunable swchunk 8192
tunable nkthread 8192
tunable nproc 5000
tunable maxfiles 8192

Database Server HW (SUT hardware)

Hardware Vendor:	HP	OS Vendor:	HP
Model Name:	rx4640	OS Name:	HP-UX 11i version 2 9/04 patch
Processor:	Intel Itanium 2	Filesystem:	vxfs
MHz:	1600	Disks:	2x73Gb 15K RPM Ultra-3
# of CPUs:	4 cores, 4 chips, 1 core/chip	Network Interface:	(1) 1000BaseT Ethernet
Memory (MB):	8192	Other Hardware:	(2) MSA1000 SAN Storage with 14x72GB 15K U320 SCSI
L1 Cache:	16KB(I)+16KB(D)	# of Systems:	1
L2 Cache:	256KB	H/W Available:	Nov-2003
Other Cache:	9MB (L3 Cache)	OS Available:	Sep-2003

Notes / Tuning Information

Kernel tunable entries:

tunable maxfiles 8192
tunable maxdsiz 4294963200
tunable hfs_revra_per_disk 256
tunable hfs_ra_per_disk 256
tunable hfs_max_revra_blocks 20
tunable hfs_max_ra_blocks 20
tunable default_disk_ir 1
tunable fs_async 1
tunable max_async_ports 768
tunable o_sync_is_o_dsync 1
tunable shmmax 4200000000
tunable maxfiles_lim 8192
tunable cmc_plat_poll 15
tunable swapmem_on 0
tunable msgmap 5122
tunable msgmax 32768
tunable vps_ceiling 64
tunable swchunk 8192
tunable shmseg 512
tunable shmmni 520
tunable semume 512
tunable semmnu 4092
tunable semmni 4096
tunable semmns 8192
tunable nswapdev 25
tunable npty 200
tunable msgtql 5120
tunable msgssz 128
tunable msgseg 20480
tunable msgmnb 65536
tunable maxvgs 80
tunable maxuprc 3277
tunable maxtsiz 1073741824
tunable ninode 8192
tunable max_thread_proc 2048
tunable nkthread 8192
tunable maxssiz 401604608
tunable dbc_min_pct 1
tunable dbc_max_pct 1
tunable create_fastlinks 1
tunable STRMSGSZ 65535
tunable nstrpty 200
tunable nproc 5000

Load Driver HW (non-SUT hardware)

Hardware Vendor:	HP	OS Vendor:	HP
Model Name:	rp3440	OS Name:	HP-UX 11i version 2 9/04 patch
Processor:	PA8800	Filesystem:	vxfs
MHz:	1000	Disks:	1x146Gb 10K RPM
# of CPUs:	4 cores, 2 chips, 2 cores/chip	Network Interface:	1000BaseT Ethernet
Memory (MB):	8192	Other Hardware:
L1 Cache:	750KB(I)+750KB(D)	# of Systems:	1
L2 Cache:	16MB	H/W Available:	Feb-2004
Other Cache:		OS Available:	Sep-2003

Notes / Tuning Information

kernel tunables entries

tunable maxdsiz 4294963200
tunable shmseg 512
tunable msgmax 32768
tunable msgmap 5122
tunable dbc_max_pct 3
tunable dbc_min_pct 3
tunable vps_ceiling 64
tunable STRMSGSZ 65535
tunable shmmni 520
tunable semume 512
tunable semmnu 4092
tunable semmns 8192
tunable semmni 4096
tunable nswapdev 25
tunable npty 200
tunable ninode 8192
tunable msgtql 5120
tunable msgssz 128
tunable msgseg 20480
tunable msgmnb 65536
tunable maxvgs 80
tunable maxuprc 3277
tunable maxtsiz 1073741824
tunable maxssiz 401604608
tunable max_thread_proc 2048
tunable hfs_revra_per_disk 256
tunable hfs_ra_per_disk 256
tunable hfs_max_revra_blocks 20
tunable hfs_max_ra_blocks 20
tunable create_fastlinks 1
tunable swapmem_on 0
tunable default_disk_ir 1
tunable swchunk 8192
tunable fs_async 1
tunable max_async_ports 768
tunable o_sync_is_o_dsync 1
tunable shmmax 12884901888
tunable nstrpty 200

Benchmark Modifications
Schema Modifications: Tablespace sizes were increased to support the Injection rate. Scripts to create the DB are included in the FDA. Table and index initrans were modified Automatic segment space management was used for all tablespaces. System managed undo was used.
Load Program Modifications: The load program was not modified.

Benchmark Modifications

Schema Modifications:

  Tablespace sizes were increased to support the Injection rate.
  Scripts to create the DB are included in the FDA.
  Table and index initrans were modified
  Automatic segment space management was used for all tablespaces.
  System managed undo was used.

Load Program Modifications:

  The load program was not modified.

Benchmark Configuration Information
Isolation Requirement Info: BEAN SPEC_REQUIREMENT Deployment Corp.CustomerEnt Repeatable Read Sel-4-Upd Corp.CustomerInventoryEnt Repeatable Read Sel-4-Upd Mfg.InventoryEnt Repeatable Read Sel-4-Upd Mfg.WorkOrderEnt Repeatable Read Sel-4-Upd Orders.OrderEnt Repeatable Read Sel-4-Upd Orders.OrderLineEnt Repeatable Read Sel-4-Upd Supplier.POEnt Repeatable Read Sel-4-Upd Supplier.POLineEnt Repeatable Read Sel-4-Upd Supplier.SComponentEnt Repeatable Read Sel-4-Upd Util.SequenceEnt Repeatable Read Sel-4-Upd Mfg.AssemblyEnt Read Committed RC Mfg.BomEnt Read Committed RC Mfg.ComponentEnt Read Committed RC Mfg.LargeOrderEnt Read Committed RC Mfg.PartEnt Read Committed RC Orders.ItemEnt Read Committed RC Supplier.SupplierCompEnt Read Committed RC Supplier.SupplierEnt Read Committed RC The ItemEnt bean was cached for 15 minute intervals by setting concurrency-strategy to ReadOnly read-timeout-seconds to 900 in bea-orders.xml deployment descriptor.
Durability Requirement Info: To ensure database durability, RAID 1 (mirroring) was used for the database logs and data on the MSA storage arrays. The application server is using a pair of mirrored disks to provide durability for all the server logs and filestore for JMS persistence.
Storage Requirement Info: An 75 minute run at an injection rate of 300 increased storage by 641 MB This extrapolates to 12.3 GB of storage for a 24 hour run. The database is configured with 1008 GB of storage.
Argument Passing Semantics: BEA WebLogic 9.0 uses pass-by-value as required by the EJB Specification.

Bill of Materials
Supplier Description Product # Qty -------- ------------------------------------------- ---------------- --- HP HP rx4640 1.6GHz/9MB 4-way bundle AB533A 1 HP 2GB DDR memory quad A6968A-0D1 7 HP 73GB 15K Hot Plug Ultra320 SCSI Drive A9897A-0D1 2 HP Rackless Form Factor for rx4640 A6979A-B01 1 HP PCI Gb-BaseT Ethernet LAN Adapter A6825A-0D1 1 HP rx4640 server bundle solution 4-IA64 support HA110A3-6KT 1 HP HP-UX 11i TCOE Media Itanium Servers T1903AA-0D1 1 HP HP-UX 11i Version 2 T1903AA-UMG 1 HP TCOE Integrity 4-sckt PPL LTU BA505AC 4 HP Itanium F-OE 4 socket servers support HA110A3-6KD 4 HP HP rx4640 1.6GHz/9MB 4-way bundle AB533A 1 HP 2GB DDR memory quad A6968A-0D1 3 HP 73GB 15K Hot Plug Ultra320 SCSI Drive A9897A-0D1 1 HP Rackless Form Factor for rx4640 A6979A-B01 1 HP PCI Gb-BaseT Ethernet LAN Adapter A6825A-0D1 1 HP PCI-X 2Gb Fibre Channel HBA A6795A-0D1 2 HP rx4640 server bundle solution 4-IA64 support HA110A3-6KT 1 HP HP-UX 11i TCOE Media Itanium Servers T1903AA-0D1 1 HP HP-UX 11i Version 2 T1903AA-UMG 1 HP TCOE Integrity 4-sckt PPL LTU BA505AC 4 HP Itanium F-OE 4 socket servers support HA110A3-6KD 4 HP ProCurve 2848 Switch J4904A 1 HP Modular SAN Array 1000 201723-B22 2 HP 72GB 15K U320 Pluggable Hard Drive 286778-B22 28 HP Support - 3yr 24x7 HA109A3 #6FG 2 BEA BEA WebLogic Server 9.0 License (per CPU) 4 BEA 3-year 24x7x4 Support for WebLogic Server 4 Oracle Oracle10g Database Release Enterprise Edition 4 v10.1.0.4 Oracle Oracle Database Server Support Package for 3 years 1

Bill of Materials


Supplier  Description                                   Product #          Qty
--------  -------------------------------------------   ----------------   ---
HP        HP rx4640 1.6GHz/9MB 4-way bundle             AB533A               1
HP        2GB DDR memory quad                           A6968A-0D1           7
HP        73GB 15K Hot Plug Ultra320 SCSI Drive         A9897A-0D1           2
HP        Rackless Form Factor for rx4640               A6979A-B01           1
HP        PCI Gb-BaseT Ethernet LAN Adapter             A6825A-0D1           1
HP	  rx4640 server bundle solution 4-IA64 support  HA110A3-6KT          1
HP        HP-UX 11i TCOE Media Itanium Servers          T1903AA-0D1          1
HP        HP-UX 11i Version 2                           T1903AA-UMG          1
HP        TCOE Integrity 4-sckt PPL LTU                 BA505AC              4
HP	  Itanium F-OE 4 socket servers support         HA110A3-6KD          4

HP        HP rx4640 1.6GHz/9MB 4-way bundle             AB533A               1
HP        2GB DDR memory quad                           A6968A-0D1           3
HP        73GB 15K Hot Plug Ultra320 SCSI Drive         A9897A-0D1           1
HP        Rackless Form Factor for rx4640               A6979A-B01           1
HP        PCI Gb-BaseT Ethernet LAN Adapter             A6825A-0D1	     1
HP        PCI-X 2Gb Fibre Channel HBA                   A6795A-0D1           2
HP        rx4640 server bundle solution 4-IA64 support  HA110A3-6KT          1
HP        HP-UX 11i TCOE Media Itanium Servers          T1903AA-0D1          1
HP        HP-UX 11i Version 2                           T1903AA-UMG          1
HP        TCOE Integrity 4-sckt PPL LTU                 BA505AC              4
HP        Itanium F-OE 4 socket servers support         HA110A3-6KD          4

HP        ProCurve 2848 Switch                          J4904A               1

HP        Modular SAN Array 1000                        201723-B22           2
HP        72GB 15K U320 Pluggable Hard Drive            286778-B22          28
HP        Support - 3yr 24x7                            HA109A3 #6FG         2

BEA       BEA WebLogic Server 9.0 License (per CPU)                          4
BEA       3-year 24x7x4 Support for WebLogic Server                          4

Oracle    Oracle10g Database Release Enterprise Edition                      4
             v10.1.0.4
Oracle    Oracle Database Server Support Package for 3 years                 1

Other Benchmark Information
The submission used round-robin DNS for load-balance of all network requests. The DNS server was hosted on the database server. This submission used the xerces implementation 2.6.2 provided with WebLogic 9.0.

Other Benchmark Information

  The submission used round-robin DNS for load-balance of
  all network requests. The DNS server was hosted
  on the database server.

  This submission used the xerces implementation 2.6.2 provided
  with WebLogic 9.0.

General Notes
The only errors in the driver log files were those that are normally generated by this benchmark. Database checkpoints during the Measurement Interval were done by using the Oracle SQLPlus command: alter system checkpoint

General Notes

The only errors in the driver log files were those that are normally generated by this benchmark.

Database checkpoints during the Measurement Interval were done by
using the Oracle SQLPlus command: alter system checkpoint

For questions about this result, please contact the submitter: HP
For other inquiries, please contact webmaster@spec.org

Benchmark run on Fri Sep 09 02:41:13 PDT 2005 by SPECjAppServer2004 v1.05
Result submitted on Wed Sep 14 03:03:01 EDT 2005
Report generated by SPECjAppServer2004 Reporter v1.03

First published at SPEC.org on 28-Sep-2005
