Creo viewset (creo-02)

The creo-02 viewset was created from traces of the graphics workload generated by the Creo 3™ and Creo 4™ applications from PTC. Model sizes range from 20 to 48 million vertices.

The viewsets include numerous rendering modes supported by the application. Order-independent transparency is enabled for all models with transparent components.

Viewset tests

Unless otherwise specified, traces were taken from PTC Creo 3:

  1. Worldcar in shaded mode, with reflections, bump mapping, image background, and ambient occlusion
  2. Worldcar in shaded mode, with reflections, bump mapping, image background, ambient occlusion, and 4x multisampled antialiasing
  3. Worldcar in shaded mode, with reflections, bump mapping, image background, ambient occlusion, and 8x multisampled antialiasing
  4. Worldcar in shaded mode
  5. Engine in shaded mode
  6. Motorcycle in shaded mode and 4x multisampled antialiasing
  7. Worldcar in shaded-with-edges mode and 4x multisampled antialiasing
  8. Engine in shaded-with-edges mode
  9. Motorcyle in shaded-with-edges mode
  10. Four bombers in shaded-with-edges mode and 8x multisampled antialiasing (traced from PTC Creo 4)
  11. Four engines in wireframe mode and 4x multisampled antialiasing
  12. Four bombers in wireframe mode (traced from PTC Creo 4)
  13. Worldcar in hidden-line mode
  14. Motorcycle in hidden-line mode and 8x multisampled antialiasing
  15. Engine in no-hidden-edge mode
  16. Four bombers in no-hidden-edge mode and 8x multisampled antialiasing (traced from PTC Creo 4)

Worldcar model courtesy of PTC.

 Bomber engines courtesy of Dave Goetsch.

 Bomber body courtesy of TurboSquid and Mesh Factory. To see more work, please go to: http://www.turbosquid.com/Search/Artists/Mesh-Factory
