| CPU2006 license: | 49 | Test date: | Aug-2007 |
|---|---|---|---|
| Test sponsor: | Advanced Micro Devices | Hardware Availability: | Oct-2007 |
| Tested by: | Advanced Micro Devices | Software Availability: | Oct-2007 |
SPEC has determined that this result was not in compliance with
the SPEC CPU2006 run and reporting rules. Specifically, the
submitter reported that the result would not meet the SPEC OSG
requirements for continued availability.
| Hardware | |
|---|---|
| CPU Name: | AMD Opteron 8350 |
| CPU Characteristics: | |
| CPU MHz: | 2000 |
| FPU: | Integrated |
| CPU(s) enabled: | 16 cores, 4 chips, 4 cores/chip |
| CPU(s) orderable: | 1 to 4 chips |
| Primary Cache: | 64 KB I + 64 KB D on chip per core |
| Secondary Cache: | 512 KB I+D on chip per core |
| L3 Cache: | 2 MB I+D on chip per chip |
| Other Cache: | None |
| Memory: | 32 GB (16x2GB, DDR2-667 CL5 Reg Dual Rank) |
| Disk Subsystem: | SATA, 250 GB, 7200 RPM |
| Other Hardware: | None |
| Software | |
|---|---|
| Operating System: | SuSE Linux Enterprise Server 10 SP1 64-bit kernel |
| Compiler: | The Portland Group (PGI) PGI pgf90 7.1-0 Fortran Compiler PGI pgcc 7.1-0 C Compiler QLogic PathScale Compiler Suite PathScale pathf95 3.0 Fortran Compiler PathScale pathcc 3.0 C Compiler PathScale pathCC 3.0 C++ Compiler |
| Auto Parallel: | No |
| File System: | ReiserFS |
| System State: | Multi-user, run level 3 |
| Base Pointers: | 64-bit |
| Peak Pointers: | 32/64-bit |
| Other Software: | none |
Results Table
| Benchmark | Base | Peak | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Copies | Seconds | Ratio | Seconds | Ratio | Seconds | Ratio | Copies | Seconds | Ratio | Seconds | Ratio | Seconds | Ratio | |
| Results appear in the order in which they were run. Bold underlined text indicates a median measurement. | ||||||||||||||
| 410.bwaves | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 416.gamess | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 433.milc | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 434.zeusmp | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 435.gromacs | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 436.cactusADM | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 437.leslie3d | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 444.namd | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 447.dealII | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 450.soplex | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 453.povray | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 454.calculix | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 459.GemsFDTD | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 465.tonto | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 470.lbm | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 481.wrf | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 482.sphinx3 | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
Operating System Notes
'ulimit -s unlimited' was used to set environment stack size 'ulimit -l 4915200' was used to set environment locked pages in memory quantity 'numactl' was used to bind copies to the cores Set vm/nr_hugepages=2400 in /etc/sysctl.conf mount -t hugetlbfs nodev /mnt/hugepages Environment variable PGI_HUGE_PAGES set to 150
General Notes
The tested system can be assembled using an EMACS PSL-6701P-SATA 700-Watt 12V power supply.
Base Compiler Invocation
C benchmarks:
| pgcc |
C++ benchmarks:
| pgcpp |
Fortran benchmarks:
| pgf95 |
Benchmarks using both Fortran and C:
| pgcc pgf95 |
Base Portability Flags
| 410.bwaves: | -DSPEC_CPU_LP64 |
| 416.gamess: | -DSPEC_CPU_LP64 |
| 433.milc: | -DSPEC_CPU_LP64 |
| 434.zeusmp: | -DSPEC_CPU_LP64 |
| 435.gromacs: | -DSPEC_CPU_LP64 -Mnomain |
| 436.cactusADM: | -DSPEC_CPU_LP64 -Mnomain |
| 437.leslie3d: | -DSPEC_CPU_LP64 |
| 444.namd: | -DSPEC_CPU_LP64 |
| 447.dealII: | -DSPEC_CPU_LP64 |
| 450.soplex: | -DSPEC_CPU_LP64 |
| 453.povray: | -DSPEC_CPU_LP64 |
| 454.calculix: | -DSPEC_CPU_LP64 -Mnomain |
| 459.GemsFDTD: | -DSPEC_CPU_LP64 |
| 465.tonto: | -DSPEC_CPU_LP64 |
| 470.lbm: | -DSPEC_CPU_LP64 |
| 481.wrf: | -DSPEC_CPU_LP64 -DSPEC_CPU_CASE_FLAG -DSPEC_CPU_LINUX |
| 482.sphinx3: | -DSPEC_CPU_LP64 |
Base Optimization Flags
C benchmarks:
| -fast -Mipa=fast -Mipa=inline -Mfprelaxed -Msmartalloc=huge:448 -tp barcelona-64 -Bstatic_pgi |
C++ benchmarks:
| -fast -Mipa=fast -Mipa=inline -Mfprelaxed -Msmartalloc=huge:448 --zc_eh -tp barcelona-64 -Bstatic_pgi |
Fortran benchmarks:
| -fast -Mipa=fast -Mipa=inline -Mfprelaxed -Msmartalloc=huge:448 -tp barcelona-64 -Bstatic_pgi |
Benchmarks using both Fortran and C:
| -fast -Mipa=fast -Mipa=inline -Mfprelaxed -Msmartalloc=huge:448 -tp barcelona-64 -Bstatic_pgi |
Base Other Flags
C benchmarks:
| -w |
C++ benchmarks:
| -w |
Fortran benchmarks:
| -w |
Benchmarks using both Fortran and C:
| -w |
Peak Compiler Invocation
C benchmarks (except as noted below):
| pathcc | |
| 433.milc: | pgcc |
C++ benchmarks (except as noted below):
| pathCC | |
| 444.namd: | pgcpp |
| 453.povray: | pgcpp |
Fortran benchmarks (except as noted below):
| pathf95 | |
| 434.zeusmp: | pgf95 |
| 465.tonto: | pgf95 |
Benchmarks using both Fortran and C (except as noted below):
| pgcc pgf95 | |
| 436.cactusADM: | pathcc pathf95 |
Peak Portability Flags
| 410.bwaves: | -DSPEC_CPU_LP64 |
| 416.gamess: | -DSPEC_CPU_LP64 |
| 433.milc: | -DSPEC_CPU_LP64 |
| 434.zeusmp: | -DSPEC_CPU_LP64 |
| 435.gromacs: | -DSPEC_CPU_LP64 -Mnomain |
| 436.cactusADM: | -DSPEC_CPU_LP64 -fno-second-underscore |
| 437.leslie3d: | -DSPEC_CPU_LP64 |
| 444.namd: | -DSPEC_CPU_LP64 |
| 453.povray: | -DSPEC_CPU_LP64 |
| 454.calculix: | -DSPEC_CPU_LP64 -Mnomain |
| 459.GemsFDTD: | -DSPEC_CPU_LP64 |
| 465.tonto: | -DSPEC_CPU_LP64 |
| 470.lbm: | -DSPEC_CPU_LP64 |
| 481.wrf: | -DSPEC_CPU_LP64 -DSPEC_CPU_CASE_FLAG -DSPEC_CPU_LINUX |
| 482.sphinx3: | -DSPEC_CPU_LP64 |
Peak Optimization Flags
C benchmarks:
| 433.milc: | -Mpfi(pass 1) -Mipa=fast(pass 2) -Mipa=inline(pass 2) -Mipa=noarg(pass 2) -Mpfo(pass 2) -fast -O4 -Mdse -Mfprelaxed -Msmartalloc=huge:448 -tp barcelona-64 -Bstatic_pgi |
| 470.lbm: | -Ofast |
| 482.sphinx3: | -fb_create fbdata(pass 1) -fb_opt fbdata(pass 2) -O3 -OPT:Ofast -WOPT:aggstr=0 -m32 |
C++ benchmarks:
| 444.namd: | -fast -O4 -Mfprelaxed -Msmartalloc=huge:448 --zc_eh -tp barcelona-64 -Mnodepchk -Mprefetch -Msafe_lastval -Msafeptr=static -Mstride0 -Munroll=n:4 -Mvect=noidiom -Mvect=prefetch -Bstatic_pgi |
| 447.dealII: | -Ofast -INLINE:aggressive=on -OPT:malloc_alg=1 -m32 -fno-exceptions |
| 450.soplex: | -fb_create fbdata(pass 1) -fb_opt fbdata(pass 2) -m32 -O3 -OPT:IEEE_arith=3 -CG:load_exe=0 -CG:movnti=1 -LNO:minvariant=off -LNO:prefetch=1 -fno-exceptions |
| 453.povray: | basepeak = yes |
Fortran benchmarks:
| 410.bwaves: | -fb_create fbdata(pass 1) -fb_opt fbdata(pass 2) -O3 -OPT:Ofast -OPT:IEEE_arith=3 -LNO:blocking=off -LNO:ignore_feedback=off |
| 416.gamess: | -fb_create fbdata(pass 1) -fb_opt fbdata(pass 2) -O2 -OPT:Ofast -OPT:ro=3 -OPT:unroll_size=256 |
| 434.zeusmp: | basepeak = yes |
| 437.leslie3d: | -Ofast -OPT:malloc_alg=1 |
| 459.GemsFDTD: | -Ofast -LNO:fission=2 -LNO:prefetch=0 |
| 465.tonto: | -fast -O4 -Mfprelaxed -Msmartalloc=huge:448 -Mipa=fast -Mipa=inline -Mvect=noaltcode -tp barcelona-64 -Bstatic_pgi |
Benchmarks using both Fortran and C:
| 435.gromacs: | -fast -Mfpapprox=rsqrt -Mipa=fast -Mipa=inline -Mfprelaxed -Msmartalloc=huge:448 -tp barcelona-64 -Bstatic_pgi |
| 436.cactusADM: | -fb_create fbdata(pass 1) -fb_opt fbdata(pass 2) -O3 -LNO:prefetch=3 -LNO:prefetch_ahead=5 -LNO:ou_prod_max=10 -LNO:full_unroll=5 -ipa |
| 454.calculix: | basepeak = yes |
| 481.wrf: | -fast -Mfprelaxed -Msmartalloc=huge:448 -Mvect=noaltcode -tp barcelona-64 -Bstatic_pgi |
Peak Other Flags
C benchmarks:
| 433.milc: | -w |
C++ benchmarks (except as noted below):
| -w | |
| 447.dealII: | -static |
| 450.soplex: | No flags used |
Fortran benchmarks:
| 434.zeusmp: | -w |
| 465.tonto: | -w |
Benchmarks using both Fortran and C (except as noted below):
| -w | |
| 436.cactusADM: | No flags used |
