| CPU2006 license: | 49 | Test date: | Aug-2007 |
|---|---|---|---|
| Test sponsor: | Advanced Micro Devices | Hardware Availability: | Oct-2007 |
| Tested by: | Advanced Micro Devices | Software Availability: | Oct-2007 |
SPEC has determined that this result was not in compliance with
the SPEC CPU2006 run and reporting rules. Specifically, the
submitter reported that the result would not meet the SPEC OSG
requirements for continued availability.
| Hardware | |
|---|---|
| CPU Name: | AMD Opteron 8350 |
| CPU Characteristics: | |
| CPU MHz: | 2000 |
| FPU: | Integrated |
| CPU(s) enabled: | 16 cores, 4 chips, 4 cores/chip |
| CPU(s) orderable: | 1 to 4 chips |
| Primary Cache: | 64 KB I + 64 KB D on chip per core |
| Secondary Cache: | 512 KB I+D on chip per core |
| L3 Cache: | 2 MB I+D on chip per chip |
| Other Cache: | None |
| Memory: | 32 GB (16x2GB, DDR2-667 CL5 Reg Dual Rank) |
| Disk Subsystem: | SATA, 250 GB, 7200 RPM |
| Other Hardware: | None |
| Software | |
|---|---|
| Operating System: | SuSE Linux Enterprise Server 10 SP1 64-bit kernel |
| Compiler: | The Portland Group (PGI) PGI pgcc 7.1-0 C Compiler PGI pgCC 7.1-0 C++ Compiler QLogic PathScale Compiler Suite PathScale pathcc 3.0 C Compiler PathScale pathCC 3.0 C++ Compiler |
| Auto Parallel: | No |
| File System: | ReiserFS |
| System State: | Multi-user, run level 3 |
| Base Pointers: | 32/64-bit |
| Peak Pointers: | 32/64-bit |
| Other Software: | SmartHeap 8.0 32-bit Library for Linux |
Results Table
| Benchmark | Base | Peak | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Copies | Seconds | Ratio | Seconds | Ratio | Seconds | Ratio | Copies | Seconds | Ratio | Seconds | Ratio | Seconds | Ratio | |
| Results appear in the order in which they were run. Bold underlined text indicates a median measurement. | ||||||||||||||
| 400.perlbench | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 401.bzip2 | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 403.gcc | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 429.mcf | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 445.gobmk | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 456.hmmer | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 458.sjeng | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 462.libquantum | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 464.h264ref | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 471.omnetpp | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 473.astar | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 483.xalancbmk | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA | NA |
Operating System Notes
'ulimit -s unlimited' was used to set environment stack size 'ulimit -l 4915200' was used to set environment locked pages in memory quantity 'numactl' was used to bind copies to the cores Set vm/nr_hugepages=2400 in /etc/sysctl.conf mount -t hugetlbfs nodev /mnt/hugepages Environment variable PGI_HUGE_PAGES set to 150
General Notes
The tested system can be assembled using an EMACS PSL-6701P-SATA 700-Watt 12V power supply.
Base Portability Flags
| 400.perlbench: | -DSPEC_CPU_LP64 -DSPEC_CPU_LINUX_X64 |
| 401.bzip2: | -DSPEC_CPU_LP64 |
| 403.gcc: | -DSPEC_CPU_LP64 |
| 429.mcf: | -DSPEC_CPU_LP64 |
| 445.gobmk: | -DSPEC_CPU_LP64 |
| 456.hmmer: | -DSPEC_CPU_LP64 |
| 458.sjeng: | -DSPEC_CPU_LP64 |
| 462.libquantum: | -DSPEC_CPU_LP64 -DSPEC_CPU_LINUX |
| 464.h264ref: | -DSPEC_CPU_LP64 |
| 483.xalancbmk: | -DSPEC_CPU_LINUX |
Base Optimization Flags
C benchmarks:
| -fast -Mipa=fast -Mipa=inline -Mipa=noarg -Mfprelaxed -Msmartalloc=huge:840 -tp barcelona-64 -Bstatic_pgi |
C++ benchmarks:
| -fastsse -Mipa=fast -Mipa=inline -Mfprelaxed -Msmartalloc=huge:448 --zc_eh -tp barcelona -Bstatic_pgi |
Peak Compiler Invocation
C benchmarks (except as noted below):
| pgcc | |
| 400.perlbench: | pathcc |
| 403.gcc: | pathcc |
| 445.gobmk: | pathcc |
| 464.h264ref: | pathcc |
C++ benchmarks (except as noted below):
| pgcpp | |
| 483.xalancbmk: | pathCC |
Peak Portability Flags
| 400.perlbench: | -DSPEC_CPU_LP64 -DSPEC_CPU_LINUX_X64 |
| 401.bzip2: | -DSPEC_CPU_LP64 |
| 445.gobmk: | -DSPEC_CPU_LP64 |
| 456.hmmer: | -DSPEC_CPU_LP64 |
| 458.sjeng: | -DSPEC_CPU_LP64 |
| 462.libquantum: | -DSPEC_CPU_LP64 -DSPEC_CPU_LINUX |
| 464.h264ref: | -DSPEC_CPU_LP64 |
| 483.xalancbmk: | -DSPEC_CPU_LINUX |
Peak Optimization Flags
C benchmarks:
C++ benchmarks:
| 471.omnetpp: | basepeak = yes |
| 473.astar: | basepeak = yes |
| 483.xalancbmk: | -Ofast -m32 -OPT:unroll_times_max=8 -L/cpu2006/work/cpu2006/SmartHeap -lsmartheap |
Peak Other Flags
C benchmarks (except as noted below):
| -w | |
| 400.perlbench: | No flags used |
| 403.gcc: | No flags used |
| 445.gobmk: | No flags used |
| 464.h264ref: | No flags used |
C++ benchmarks (except as noted below):
| -w | |
| 483.xalancbmk: | No flags used |
