SPEC® CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Dell Inc.

Dell Precision M90 (Intel T7600,
2.33 GHz)

CPU2006 license: 55 Test date: Dec-2006
Test sponsor: Dell Inc. Hardware Availability: Sep-2006
Tested by: Dell Inc. Software Availability: Nov-2006
Benchmark results graph
Hardware
CPU Name: Intel Core 2 Duo T7600
CPU Characteristics: 667 MHz System Bus
CPU MHz: 2333
FPU: Integrated
CPU(s) enabled: 2 cores, 1 chip, 2 cores/chip
CPU(s) orderable: 1 chip
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 4 MB I+D on chip per chip
L3 Cache: None
Other Cache: None
Memory: 2 GB (2x1 GB 667 MHz CL5 DDR2 SDRAM)
Disk Subsystem: 1 x 80 GB SATA 7200 RPM
Other Hardware: None
Software
Operating System: Windows XP Professional SP2
Compiler: Intel C++ Compiler 9.1 for IA32 (20061103Z)
Intel FORTRAN Compiler 9.1 for IA32 (20061103Z)
Microsoft Visual Studio 2005
MicroQuill SmartHeap Library 8.0
Auto Parallel: No
File System: NTFS
System State: Default
Base Pointers: 32-bit
Peak Pointers: 32-bit
Other Software: None

Results Table

Benchmark Base Peak
Copies Seconds Ratio Seconds Ratio Seconds Ratio Copies Seconds Ratio Seconds Ratio Seconds Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
410.bwaves 2 1362 20.0 1406 19.3 1406 19.3 2 1384 19.6 1408 19.3 1394 19.5
416.gamess 2 1435 27.3 1433 27.3 1433 27.3 2 1434 27.3 1433 27.3 1436 27.3
433.milc 2 1552 11.8 1551 11.8 1551 11.8 2 1548 11.9 1545 11.9 1548 11.9
434.zeusmp 2 794 22.9 786 23.2 805 22.6 2 814 22.4 823 22.1 822 22.2
435.gromacs 2 538 26.5 538 26.6 538 26.6 2 538 26.5 537 26.6 538 26.5
436.cactusADM 2 869 27.5 878 27.2 860 27.8 2 881 27.1 872 27.4 870 27.5
437.leslie3d 2 1431 13.1 1418 13.3 1431 13.1 2 1433 13.1 1452 12.9 1413 13.3
444.namd 2 685 23.4 684 23.4 684 23.4 2 673 23.8 673 23.8 674 23.8
447.dealII 2 898 25.5 906 25.3 900 25.4 2 878 26.0 875 26.1 878 26.1
450.soplex 2 1170 14.3 1174 14.2 1191 14.0 2 1167 14.3 1145 14.6 1148 14.5
453.povray 2 327 32.5 327 32.5 327 32.5 2 261 40.8 261 40.8 260 40.9
454.calculix 2 796 20.7 798 20.7 795 20.7 2 791 20.9 785 21.0 789 20.9
459.GemsFDTD 2 1856 11.4 1860 11.4 1855 11.4 2 1856 11.4 1860 11.4 1855 11.4
465.tonto 2 1179 16.7 1184 16.6 1176 16.7 2 1136 17.3 1133 17.4 1131 17.4
470.lbm 2 2333 11.8 2407 11.4 2332 11.8 2 2386 11.5 2400 11.4 2386 11.5
481.wrf 2 1088 20.5 1116 20.0 1086 20.6 2 1074 20.8 1103 20.3 1114 20.1
482.sphinx3 2 1617 24.1 1589 24.5 1592 24.5 2 1604 24.3 1605 24.3 1604 24.3

General Notes

 32-bit binaries were built on Windows XP Professional x64 Edition

Base Compiler Invocation

C benchmarks:

 icl   -Qc99

C++ benchmarks:

 icl

Fortran benchmarks:

 ifort

Benchmarks using both Fortran and C:

 icl   -Qc99   ifort

Base Portability Flags

436.cactusADM:  -Qlowercase   /assume:underscore
444.namd:  -TP
447.dealII:  -DDEAL_II_MEMBER_VAR_SPECIALIZATION_BUG   -DBOOST_NO_INTRINSIC_WCHAR_T
453.povray:  -DSPEC_CPU_WINDOWS_ICL
454.calculix:  -DSPEC_CPU_NOZMODIFIER   -Qlowercase
481.wrf:  -DSPEC_CPU_WINDOWS_ICL

Base Optimization Flags

C benchmarks:

 -fast   /F512000000   shlW32M.lib    -link /FORCE:MULTIPLE

C++ benchmarks:

 -fast   -Qcxx_features   /F512000000   shlW32M.lib    -link /FORCE:MULTIPLE

Fortran benchmarks:

 -fast   /F1000000000    -link /FORCE:MULTIPLE

Benchmarks using both Fortran and C:

 -fast   /F1000000000    -link /FORCE:MULTIPLE

Peak Compiler Invocation

C benchmarks:

 icl   -Qc99

C++ benchmarks:

 icl

Fortran benchmarks:

 ifort

Benchmarks using both Fortran and C:

 icl   -Qc99   ifort

Peak Portability Flags

436.cactusADM:  -Qlowercase   /assume:underscore
444.namd:  -TP
447.dealII:  -DDEAL_II_MEMBER_VAR_SPECIALIZATION_BUG   -DBOOST_NO_INTRINSIC_WCHAR_T
453.povray:  -DSPEC_CPU_WINDOWS_ICL
454.calculix:  -DSPEC_CPU_NOZMODIFIER   -Qlowercase
481.wrf:  -DSPEC_CPU_WINDOWS_ICL

Peak Optimization Flags

C benchmarks:

 ONESTEP   -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   /F512000000   shlW32M.lib    -link /FORCE:MULTIPLE

C++ benchmarks:

 ONESTEP   -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   -Qcxx_features   /F512000000   shlW32M.lib    -link /FORCE:MULTIPLE

Fortran benchmarks:

410.bwaves:  ONESTEP   -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   /F1000000000    -link /FORCE:MULTIPLE
416.gamess:  ONESTEP   -fast   /F1000000000    -link /FORCE:MULTIPLE
434.zeusmp:  Same as 410.bwaves
437.leslie3d:  Same as 410.bwaves
459.GemsFDTD:  basepeak = yes
465.tonto:  Same as 410.bwaves

Benchmarks using both Fortran and C:

435.gromacs:  -fast   /F1000000000    -link /FORCE:MULTIPLE
436.cactusADM:  -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   /F1000000000    -link /FORCE:MULTIPLE
454.calculix:  Same as 436.cactusADM
481.wrf:  Same as 435.gromacs

The flags file that was used to format this result can be browsed at
http://www.spec.org/cpu2006/flags/dell.cpu2006.ic91.flags.20090715.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/cpu2006/flags/dell.cpu2006.ic91.flags.20090715.xml.
